5ZFI

Mouse kallikrein 7 in complex with 6-benzyl-1,4-diazepan-7-one derivative


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.227 (Depositor), 0.230 (DCC)
  • R-Value Work:
    0.185 (Depositor), 0.180 (DCC)
  • R-Value Observed:
    0.188 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted 9C9Click on this verticalbar to view details

This is version 1.3 of the entry. See complete history


Literature

Structure-based drug design to overcome species differences in kallikrein 7 inhibition of 1,3,6-trisubstituted 1,4-diazepan-7-ones.

Murafuji, H.Sugawara, H.Goto, M.Oyama, Y.Sakai, H.Imajo, S.Tomoo, T.Muto, T.

(2018) Bioorg Med Chem 26: 3639-3653

  • DOI: https://doi.org/10.1016/j.bmc.2018.05.044
  • Primary Citation of Related Structures:
    5ZFH, 5ZFI

  • PubMed Abstract:

    A series of 1,3,6-trisubstituted 1,4-diazepan-7-ones were prepared as kallikrein 7 (KLK7, stratum corneum chymotryptic enzyme) inhibitors. Previously reported compounds 1-3 were potent human KLK7 inhibitors; however, they did not exhibit inhibitory activity against mouse KLK7. Comparison of the human and mouse KLK7 structures reveals the cause of this species differences; therefore, compounds that could inhibit both KLK7s were designed, synthesized, and evaluated. Through this structure-based drug design, compound 22g was identified as an inhibitor against human and mouse KLK7, and only one of the enantiomers, (-)-22g, exhibited potent inhibitory activity. Furthermore, the crystal structure of mouse KLK7 complexed with 22g enabled the elucidation of structure-activity relationships and justified 22g as a valuable compound to overcome the species differences.


  • Organizational Affiliation

    Asubio Pharma Co., Ltd., 6-4-3 Minatojima-Minamimachi, Chuo-ku, Kobe, Hyogo 650-0047, Japan. Electronic address: murafuji.hidenobu.bj@daiichisankyo.co.jp.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Kallikrein-7224Mus musculusMutation(s): 0
Gene Names: Klk7Prss6Scce
EC: 3.4.21.117
UniProt
Find proteins for Q91VE3 (Mus musculus)
Explore Q91VE3
Go to UniProtKB:  Q91VE3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ91VE3
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
9C9 (Subject of Investigation/LOI)
Query on 9C9

Download Ideal Coordinates CCD File
B [auth A]2-[(3Z,6R)-6-[(2,6-dichlorophenyl)methyl]-3-(dimethylhydrazinylidene)-7-oxo-1,4-diazepan-1-yl]-N-[3-(1-methyl-1H-pyrazol-4-yl)phenyl]acetamide
C26 H29 Cl2 N7 O2
GKZIYEBJQVXMQL-GOSISDBHSA-N
TRS
Query on TRS

Download Ideal Coordinates CCD File
C [auth A]2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.227 (Depositor), 0.230 (DCC)
  • R-Value Work:  0.185 (Depositor), 0.180 (DCC)
  • R-Value Observed: 0.188 (Depositor)
Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.85α = 90
b = 70.85β = 90
c = 98.022γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted 9C9Click on this verticalbar to view details

Entry History

Deposition Data

  • Released Date: 2018-06-27
  • Deposition Author(s): Sugawara, H.

Revision History  (Full details and data files)

  • Version 1.0: 2018-06-27
    Type: Initial release
  • Version 1.1: 2018-07-04
    Changes: Data collection, Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-11-13
    Changes: Structure summary
