5Y30

Crystal structure of LGI1 LRR domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.166
  • R-Value Observed: 0.167

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural basis of epilepsy-related ligand-receptor complex LGI1-ADAM22.

Yamagata, A.Miyazaki, Y.Yokoi, N.Shigematsu, H.Sato, Y.Goto-Ito, S.Maeda, A.Goto, T.Sanbo, M.Hirabayashi, M.Shirouzu, M.Fukata, Y.Fukata, M.Fukai, S.

(2018) Nat Commun 9: 1546-1546

  • DOI: https://doi.org/10.1038/s41467-018-03947-w
  • Primary Citation of Related Structures:
    5Y2Z, 5Y30, 5Y31

  • PubMed Abstract:

    Epilepsy is a common brain disorder throughout history. Epilepsy-related ligand-receptor complex, LGI1-ADAM22, regulates synaptic transmission and has emerged as a determinant of brain excitability, as their mutations and acquired LGI1 autoantibodies cause epileptic disorders in human. Here, we report the crystal structure of human LGI1-ADAM22 complex, revealing a 2:2 heterotetrameric assembly. The hydrophobic pocket of the C-terminal epitempin-repeat (EPTP) domain of LGI1 binds to the metalloprotease-like domain of ADAM22. The N-terminal leucine-rich repeat and EPTP domains of LGI1 mediate the intermolecular LGI1-LGI1 interaction. A pathogenic R474Q mutation of LGI1, which does not exceptionally affect either the secretion or the ADAM22 binding, is located in the LGI1-LGI1 interface and disrupts the higher-order assembly of the LGI1-ADAM22 complex in vitro and in a mouse model for familial epilepsy. These studies support the notion that the LGI1-ADAM22 complex functions as the trans-synaptic machinery for precise synaptic transmission.


  • Organizational Affiliation

    Institute for Quantitative Biosciences, The University of Tokyo, Tokyo, 113-0032, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Leucine-rich glioma-inactivated protein 1210Homo sapiensMutation(s): 0
Gene Names: LGI1EPTUNQ775/PRO1569
UniProt & NIH Common Fund Data Resources
Find proteins for O95970 (Homo sapiens)
Explore O95970
Go to UniProtKB:  O95970
PHAROS:  O95970
GTEx:  ENSG00000108231
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO95970
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.166
  • R-Value Observed: 0.167
  • Space Group: P 61
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.252α = 90
b = 65.252β = 90
c = 109.741γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
BALBESphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-05-02
    Type: Initial release
  • Version 1.1: 2023-11-22
    Changes: Data collection, Database references, Refinement description
  • Version 1.2: 2024-10-30
    Changes: Structure summary
