5Y2L | pdb_00005y2l

Crystal structure of a group 2 HA binding antibody AF4H1K1 Fab in complex with the 1968 H3N2 pandemic (H3-AC/68) hemagglutinin

PDB DOI: https://doi.org/10.2210/pdb5Y2L/pdb

Classification: ANTIMICROBIAL PROTEIN
Organism(s): Influenza A virus (A/Aichi/2/1968(H3N2)), Homo sapiens
Expression System: Trichoplusia ni, Homo sapiens
Mutation(s): No

Deposited: 2017-07-26 Released: 2019-01-30
Deposition Author(s): Xiao, H., Qi, J., Gao, F.G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free:
0.244 (Depositor), 0.252 (DCC)
R-Value Work:
0.212 (Depositor), 0.222 (DCC)
R-Value Observed:
0.214 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.1 of the entry. See complete history.

Literature

An H3-clade neutralizing antibody screened from an H7N9 patient that binds group 2 influenza A hemagglutinins

Xiao, H., Qi, J., Gao, F.G.

To be published.

Macromolecule Content

Total Structure Weight: 107.05 kDa
Atom Count: 7,189
Modeled Residue Count: 916
Deposited Residue Count: 958
Unique protein chains: 4

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hemagglutinin	A	329	Influenza A virus (A/Aichi/2/1968(H3N2))	Mutation(s): 0 Gene Names: HA
UniProt
Find proteins for P03437 (Influenza A virus (strain A/Aichi/2/1968 H3N2)) Explore P03437 Go to UniProtKB: P03437
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P03437
Glycosylation
Glycosylation Sites: 4	Glycosylation Focus chain A
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Hemagglutinin	B	176	Influenza A virus (A/Aichi/2/1968(H3N2))	Mutation(s): 0 Gene Names: HA
UniProt
Find proteins for P03437 (Influenza A virus (strain A/Aichi/2/1968 H3N2)) Explore P03437 Go to UniProtKB: P03437
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P03437
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
a group 2 HA binding antibody AF4H1K1 Fab heavy chain	C [auth I]	233	Homo sapiens	Mutation(s): 0

Find similar proteins by:

| 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
a group 2 HA binding antibody AF4H1K1 Fab light chain	D [auth J]	220	Homo sapiens	Mutation(s): 0

Oligosaccharides

Help

Entity ID: 5
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	E [auth C], F [auth D]	2		N-Glycosylation	Interactions Focus chain E [auth C] Focus chain F [auth D] Interactions & Density Focus chain E [auth C] Focus chain F [auth D]
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A]	G [auth A], H [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free: 0.244 (Depositor), 0.252 (DCC)
R-Value Work: 0.212 (Depositor), 0.222 (DCC)
R-Value Observed: 0.214 (Depositor)

Space Group: H 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 157.482	α = 90
b = 157.482	β = 90
c = 355.344	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-01-30

Deposition Author(s):

Xiao, H.

Qi, J.

Gao, F.G.

Revision History (Full details and data files)

Version 1.0: 2019-01-30
Type: Initial release
Version 1.1: 2020-03-04
Changes: Data collection, Derived calculations
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Derived calculations, Structure summary
Version 2.1: 2024-11-13
Changes: Data collection, Database references, Structure summary
