5XUY

Crystal structure of ATG101-ATG13HORMA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.275
  • R-Value Work: 0.237
  • R-Value Observed: 0.239

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

The C-terminal region of ATG101 bridges ULK1 and PtdIns3K complex in autophagy initiation.

Kim, B.-W.Jin, Y.Kim, J.Kim, J.H.Jung, J.Kang, S.Kim, I.Y.Kim, J.Cheong, H.Song, H.K.

(2018) Autophagy 14: 2104-2116

  • DOI: https://doi.org/10.1080/15548627.2018.1504716
  • Primary Citation of Related Structures:
    5XUY, 5XV3, 5XV4, 5XV6

  • PubMed Abstract:

    The initiation of macroautophagy/autophagy is tightly regulated by the upstream ULK1 kinase complex, which affects many downstream factors including the PtdIns3K complex. The phosphorylation of the right position at the right time on downstream molecules is governed by proper complex formation. One component of the ULK1 complex, ATG101, known as an accessory protein, is a stabilizer of ATG13 in cells. The WF finger region of ATG101 plays an important role in the recruitment of WIPI1 (WD repeat domain, phosphoinositide interacting protein 1) and ZFYVE1 (zinc finger FYVE-type containing 1). Here, we report that the C-terminal region identified in the structure of the human ATG101-ATG13 HORMA complex is responsible for the binding of the PtdIns3K complex. This region adopts a β-strand conformation in free ATG101, but either an α-helix or random coil in our ATG101-ATG13 HORMA complex, which protrudes from the core and interacts with other molecules. The C-terminal deletion of ATG101 shows a significant defect in the interaction with PtdIns3K components and subsequently impairs autophagosome formation. This result clearly presents an additional role of ATG101 for bridging the ULK1 and PtdIns3K complexes in the mammalian autophagy process. Abbreviations: ATG: autophagy related; BECN1: beclin 1; GFP: green fluorescent protein; HORMA: Hop1p/Rev7p/MAD2; HsATG13 HORMA : HORMA domain of ATG13 from Homo sapiens; KO: knockout; MAD2: mitotic arrest deficient 2 like 1; MAP1LC3/LC3: microtubule associated protein 1 light chain 3; PIK3C3/VPS34: phosphatidylinositol 3-kinase catalytic subunit type 3; PIK3R4/VPS15: phosphoinositide-3-kinase regulatory subunit 4; PtdIns3K: phosphatidylinositol 3-kinase; RB1CC1/FIP200: RB1 inducible coiled-coil 1; SAXS: small-angle X-ray scattering; ScAtg13 HORMA : HORMA domain of Atg13 from Sccharomyces cerevisiae; SEC-SAXS: size-exclusion chromatography with small-angle X-ray scattering; SpAtg13 HORMA : HORMA domain of Atg13 from Schizosaccharomyces pombe; SQSTM1/p62: sequestosome 1; ULK1: unc51-like autophagy activating kinase 1; UVRAG: UV radiation resistance associated; WIPI1: WD repeat domain: phosphoinositide interacting 1; ZFYVE1/DFCP1: zinc finger FYVE-type containing 1.


  • Organizational Affiliation

    a Department of Life Sciences , Korea University , Seongbuk-gu, Seoul , Republic of Korea.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Autophagy-related protein 13
A, C
190Homo sapiensMutation(s): 0
Gene Names: ATG13KIAA0652
UniProt & NIH Common Fund Data Resources
Find proteins for O75143 (Homo sapiens)
Explore O75143
Go to UniProtKB:  O75143
PHAROS:  O75143
GTEx:  ENSG00000175224
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO75143
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Autophagy-related protein 101
B, D
218Homo sapiensMutation(s): 3
Gene Names: ATG101C12orf44PP894
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BSB4 (Homo sapiens)
Explore Q9BSB4
Go to UniProtKB:  Q9BSB4
PHAROS:  Q9BSB4
GTEx:  ENSG00000123395
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BSB4
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.275
  • R-Value Work: 0.237
  • R-Value Observed: 0.239
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.99α = 90
b = 125.177β = 102.08
c = 100.76γ = 90
Software Package:
Software NamePurpose
HKL-2000data scaling
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-07-04
    Type: Initial release
  • Version 1.1: 2019-01-16
    Changes: Data collection, Database references
  • Version 1.2: 2024-03-27
    Changes: Data collection, Database references
