5UW1 | pdb_00005uw1

Activated state yGsy2p in complex with UDP-galactose

• PDB DOI: https://doi.org/10.2210/pdb5UW1/pdb

• Classification: TRANSFERASE
• Organism(s): Saccharomyces cerevisiae S288C
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2017-02-20 Released: 2018-02-28
• Deposition Author(s): Mahalingan, K.K., Hurley, T.D.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.26 Å
• R-Value Free:
  0.230 (Depositor), 0.226 (DCC)
• R-Value Work:
  0.185 (Depositor), 0.188 (DCC)
• R-Value Observed:
  0.188 (Depositor)

Starting Model: experimental

Literature

Activated state yGsy2p in complex with UDP-galactose

Mahalingan, K.K., Hurley, T.D.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 330.58 kDa
• Atom Count: 20,503
• Modeled Residue Count: 2,544
• Deposited Residue Count: 2,880
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycogen [starch] synthase isoform 2	A, B, C, D	720	Saccharomyces cerevisiae S288C	Mutation(s): 1  Gene Names: GSY2, YLR258W, L8479.8 EC: 2.4.1.11
UniProt
Find proteins for P27472 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P27472  Go to UniProtKB:  P27472

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GDU	E [auth A], G [auth B], I [auth C], K [auth D]	GALACTOSE-URIDINE-5'-DIPHOSPHATE C15 H24 N2 O17 P2 HSCJRCZFDFQWRP-ABVWGUQPSA-N
G6P	F [auth A], H [auth B], J [auth C], L [auth D]	6-O-phosphono-alpha-D-glucopyranose C6 H13 O9 P NBSCHQHZLSJFNQ-DVKNGEFBSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.26 Å
• R-Value Free:  0.230 (Depositor), 0.226 (DCC)
• R-Value Work:  0.185 (Depositor), 0.188 (DCC)
• R-Value Observed: 0.188 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 193.665	α = 90
b = 206.446	β = 90
c = 205.099	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-02-28
Deposition Author(s): Mahalingan, K.K., Hurley, T.D.

Revision History

• Version 1.0: 2018-02-28
  Type: Initial release

• Version 1.1: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Data collection, Derived calculations, Structure summary
• Version 1.2: 2023-10-04
  Changes: Data collection, Database references, Refinement description, Structure summary
