5UR3 | pdb_00005ur3

Kaposi's Sarcoma Herpesvirus Protease in Complex with Allosteric Inhibitor

PDB DOI: https://doi.org/10.2210/pdb5UR3/pdb

Classification: HYDROLASE/HYDROLASE inhibitor
Organism(s): Human gammaherpesvirus 8
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-02-09 Released: 2017-03-08
Deposition Author(s): Acker, T.M., Gable, J., Bohn, M.-F., Craik, C.S.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.223 (Depositor), 0.221 (DCC)
R-Value Work:
0.180 (Depositor), 0.182 (DCC)
R-Value Observed:
0.182 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5UR3

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history.

Literature

Kaposi's Sarcoma Herpesvirus Protease in Complex with Allosteric Inhibitor

Acker, T.M., Craik, C.S., Bohn, M.-F.

To be published.

Macromolecule Content

Total Structure Weight: 43.67 kDa
Atom Count: 3,320
Modeled Residue Count: 382
Deposited Residue Count: 386
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
KSHV protease	A, B	193	Human gammaherpesvirus 8	Mutation(s): 0 Gene Names: ORF17
UniProt
Find proteins for O40922 (Human herpesvirus 8) Explore O40922 Go to UniProtKB: O40922
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O40922
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
8OY Query on 8OY Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] SDF format, chain E [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain E [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain E [auth B]	C [auth A], D [auth B], E [auth B]	4-{[6-(cyclohexylmethyl)pyridine-2-carbonyl]amino}-3-(phenylamino)benzoic acid C₂₆ H₂₇ N₃ O₃ PIPBPJWDZSBLMQ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Focus chain E [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B] Focus chain E [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.223 (Depositor), 0.221 (DCC)
R-Value Work: 0.180 (Depositor), 0.182 (DCC)
R-Value Observed: 0.182 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.4	α = 90
b = 92.86	β = 90
c = 118.93	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data reduction
SCALA	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-03-08

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	NIH R01 GM104659
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	1F32GM111012

Revision History (Full details and data files)

Version 1.0: 2017-03-08
Type: Initial release
Version 1.1: 2017-09-27
Changes: Author supporting evidence
Version 1.2: 2020-01-01
Changes: Author supporting evidence
Version 1.3: 2024-03-06
Changes: Data collection, Database references
