5UNE | pdb_00005une

Dimerized Structure Gives Further Insight Into the Function of the Novel RNA Gene: HAR1

PDB DOI: https://doi.org/10.2210/pdb5UNE/pdb
NAKB: 5UNE

Classification: RNA
Organism(s): Homo sapiens
Mutation(s): No

Deposited: 2017-01-30 Released: 2017-03-29
Deposition Author(s): Lares, M., Scott, W.G.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free:
0.249 (Depositor), 0.248 (DCC)
R-Value Work:
0.201 (Depositor), 0.202 (DCC)
R-Value Observed:
0.206 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5UNE

This is version 1.4 of the entry. See complete history.

Literature

Dimerized Structure Gives Further Insight Into the Function of the Novel RNA Gene: HAR1

Lares, M., Scott, W.G., Kimberly, T.

To be published.

Macromolecule Content

Total Structure Weight: 30.63 kDa
Atom Count: 2,049
Modeled Residue Count: 94
Deposited Residue Count: 94
Unique nucleic acid chains: 1

Macromolecules

Find similar nucleic acids by:

(by identity cutoff)

Molecule	Chains	Length	Organism	Image
Entity ID: 1
RNA (47-MER)	A, B	47	Homo sapiens
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain C [auth B] SDF format, chain D [auth B] MOL2 format, chain C [auth B] MOL2 format, chain D [auth B] mmCIF format, chain C [auth B] mmCIF format, chain D [auth B]	C [auth B], D [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Focus chain D [auth B] Interactions & Density Focus chain C [auth B] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free: 0.249 (Depositor), 0.248 (DCC)
R-Value Work: 0.201 (Depositor), 0.202 (DCC)
R-Value Observed: 0.206 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.562	α = 90
b = 39.826	β = 111.829
c = 80.974	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
MOSFLM	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-03-29

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R01GM087721

Revision History (Full details and data files)

Version 1.0: 2017-03-29
Type: Initial release
Version 1.1: 2017-08-09
Changes: Database references
Version 1.2: 2017-09-27
Changes: Author supporting evidence
Version 1.3: 2020-01-01
Changes: Author supporting evidence
Version 1.4: 2024-03-06
Changes: Data collection, Database references
