5UHO

Crystal structure of the core catalytic domain of human O-GlcNAcase complexed with PUGNAc

• PDB DOI: https://doi.org/10.2210/pdb5UHO/pdb

• Classification: HYDROLASE
• Organism(s): Homo sapiens
• Expression System: Spodoptera frugiperda
• Mutation(s): No


• Deposited: 2017-01-11 Released: 2017-03-29
• Deposition Author(s): Klein, D.J., Elsen, N.L.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.21 Å
• R-Value Free: 0.259
• R-Value Work: 0.197
• R-Value Observed: 0.200

Literature

Crystal structure of the core catalytic domain of human O-GlcNAcase and molecular basis of activity and inhibition

Elsen, N.L., Patel, S.B., Ford, R.E., Hall, D.L., Hess, F., Kandula, H., Kornienko, M., Lumb, K.J., Reid, J., Selnick, H., Shipman, J.M., Sharma, S., Soisson, S.M., Klein, D.J.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 4-mer - A2B2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 118.25 kDa
• Atom Count: 6,967
• Modelled Residue Count: 846
• Deposited Residue Count: 1,016
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
O-GlcNAcase TIM-barrel domain	A, C	345	Homo sapiens	Mutation(s): 0  Gene Names: MGEA5, HEXC, KIAA0679, MEA5 EC: 3.2.1.169 (PDB Primary Data), 3.2.1 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for O60502 (Homo sapiens) Explore O60502  Go to UniProtKB:  O60502
PHAROS:  O60502 GTEx:  ENSG00000198408

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
O-GlcNAcase stalk domain	B, D	163	Homo sapiens	Mutation(s): 0  Gene Names: MGEA5, HEXC, KIAA0679, MEA5 EC: 3.2.1.169 (PDB Primary Data), 3.2.1 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for O60502 (Homo sapiens) Explore O60502  Go to UniProtKB:  O60502
PHAROS:  O60502 GTEx:  ENSG00000198408

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
OAN	E [auth A], F [auth C]	O-(2-ACETAMIDO-2-DEOXY D-GLUCOPYRANOSYLIDENE) AMINO-N-PHENYLCARBAMATE C15 H19 N3 O7 PBLNJFVQMUMOJY-JXZOILRNSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
OAN	BindingDB:  5UHO	Ki: min: 50, max: 50 (nM) from 2 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.21 Å
• R-Value Free: 0.259
• R-Value Work: 0.197
• R-Value Observed: 0.200
• Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 97.34	α = 90
b = 97.34	β = 90
c = 260.45	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
XDS	data reduction
Aimless	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2017-03-29
Deposition Author(s): Klein, D.J., Elsen, N.L.

Revision History

• Version 1.0: 2017-03-29
  Type: Initial release

• Version 1.1: 2024-03-06
  Changes: Data collection, Database references
