5UEQ | pdb_00005ueq

BRD4_BD2_A-1390146

PDB DOI: https://doi.org/10.2210/pdb5UEQ/pdb

Classification: SIGNALING PROTEIN/INHIBITOR
Organism(s): Homo sapiens
Expression System: Enterobacteria phage L1
Mutation(s): No

Deposited: 2017-01-03 Released: 2017-06-14
Deposition Author(s): Park, C.H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.217 (Depositor), 0.203 (DCC)
R-Value Work:
0.179 (Depositor)
R-Value Observed:
0.181 (Depositor)

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5UEQ

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Complex structure of BRD4_BD2_A-1390146

Park, C.H.

To be published.

Macromolecule Content

Total Structure Weight: 13.23 kDa
Atom Count: 1,133
Modeled Residue Count: 107
Deposited Residue Count: 109
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bromodomain-containing protein 4	A	109	Homo sapiens	Mutation(s): 0 Gene Names: BRD4, HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens) Explore O60885 Go to UniProtKB: O60885
PHAROS: O60885 GTEx: ENSG00000141867
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O60885
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
87M Query on 87M Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	N-[3-(7-methyl-1-oxo-2,6-dihydro-1H-pyrrolo[3,4-d]pyridazin-5-yl)-4-phenoxyphenyl]ethanesulfonamide C₂₁ H₂₀ N₄ O₄ S YYFWVXHZOKCWDD-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.217 (Depositor), 0.203 (DCC)
R-Value Work: 0.179 (Depositor)
R-Value Observed: 0.181 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.624	α = 90
b = 70.417	β = 90
c = 33.555	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
SCALA	data scaling
Coot	model building
BUSTER	refinement

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-06-14

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2017-06-14
Type: Initial release
Version 1.1: 2024-03-06
Changes: Data collection, Database references
Version 1.2: 2024-04-03
Changes: Refinement description
