5TEA | pdb_00005tea

Crystal structure of an inorganic pyrophosphatase from Neisseria gonorrhoeae

PDB DOI: https://doi.org/10.2210/pdb5TEA/pdb

Classification: HYDROLASE
Organism(s): Neisseria gonorrhoeae
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2016-09-20 Released: 2016-10-05
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.209 (Depositor), 0.209 (DCC)
R-Value Work:
0.170 (Depositor), 0.170 (DCC)
R-Value Observed:
0.170 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of an inorganic pyrophosphatase from

Edwards, T.E., Horanyi, P.S., Seattle Structural Genomics Center for Infectious Disease (SSGCID)

To be published.

Macromolecule Content

Total Structure Weight: 125.42 kDa
Atom Count: 8,870
Modeled Residue Count: 1,042
Deposited Residue Count: 1,110
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Inorganic pyrophosphatase	A, B, C, D, E A, B, C, D, E, F	185	Neisseria gonorrhoeae	Mutation(s): 0 Gene Names: ppa EC: 3.6.1.1
UniProt
Find proteins for Q9K0G4 (Neisseria meningitidis serogroup B (strain ATCC BAA-335 / MC58)) Explore Q9K0G4 Go to UniProtKB: Q9K0G4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9K0G4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain R [auth F] SDF format, chain P [auth E] SDF format, chain N [auth D] SDF format, chain L [auth C] SDF format, chain I [auth B] SDF format, chain G [auth A] MOL2 format, chain R [auth F] MOL2 format, chain P [auth E] MOL2 format, chain N [auth D] MOL2 format, chain L [auth C] MOL2 format, chain I [auth B] MOL2 format, chain G [auth A] mmCIF format, chain R [auth F] mmCIF format, chain P [auth E] mmCIF format, chain N [auth D] mmCIF format, chain L [auth C] mmCIF format, chain I [auth B] mmCIF format, chain G [auth A]	G [auth A] I [auth B] L [auth C] N [auth D] P [auth E] G [auth A], I [auth B], L [auth C], N [auth D], P [auth E], R [auth F]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain N [auth D] Focus chain P [auth E] Focus chain R [auth F] Interactions & Density Focus chain G [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain N [auth D] Focus chain P [auth E] Focus chain R [auth F]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain S [auth F] SDF format, chain Q [auth E] SDF format, chain O [auth D] SDF format, chain M [auth C] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain H [auth A] MOL2 format, chain S [auth F] MOL2 format, chain Q [auth E] MOL2 format, chain O [auth D] MOL2 format, chain M [auth C] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain H [auth A] mmCIF format, chain S [auth F] mmCIF format, chain Q [auth E] mmCIF format, chain O [auth D] mmCIF format, chain M [auth C] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain H [auth A]	H [auth A] J [auth B] K [auth B] M [auth C] O [auth D] H [auth A], J [auth B], K [auth B], M [auth C], O [auth D], Q [auth E], S [auth F]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth D] Focus chain Q [auth E] Focus chain S [auth F] Interactions & Density Focus chain H [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth D] Focus chain Q [auth E] Focus chain S [auth F]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.209 (Depositor), 0.209 (DCC)
R-Value Work: 0.170 (Depositor), 0.170 (DCC)
R-Value Observed: 0.170 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 142.72	α = 90
b = 65.65	β = 115.65
c = 133.21	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-10-05

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2016-10-05
Type: Initial release
Version 1.1: 2023-10-04
Changes: Data collection, Database references, Derived calculations, Refinement description
