5SZN

Protocadherin gamma A9 extracellular cadherin domains 1-5


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:
    0.295 (Depositor), 0.300 (DCC)
  • R-Value Work:
    0.241 (Depositor), 0.240 (DCC)
  • R-Value Observed:
    0.244 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted NAGClick on this verticalbar to view detailsBest fitted MANClick on this verticalbar to view details

This is version 2.3 of the entry. See complete history


Literature

gamma-Protocadherin structural diversity and functional implications.

Goodman, K.M.Rubinstein, R.Thu, C.A.Mannepalli, S.Bahna, F.Ahlsen, G.Rittenhouse, C.Maniatis, T.Honig, B.Shapiro, L.

(2016) Elife 5

  • DOI: https://doi.org/10.7554/eLife.20930
  • Primary Citation of Related Structures:
    5SZL, 5SZM, 5SZN, 5SZO, 5SZP, 5SZQ, 5SZR, 5T9T

  • PubMed Abstract:

    Stochastic cell-surface expression of α-, β-, and γ-clustered protocadherins (Pcdhs) provides vertebrate neurons with single-cell identities that underlie neuronal self-recognition. Here we report crystal structures of ectodomain fragments comprising cell-cell recognition regions of mouse γ-Pcdhs γA1, γA8, γB2, and γB7 revealing trans -homodimers, and of C-terminal ectodomain fragments from γ-Pcdhs γA4 and γB2, which depict cis -interacting regions in monomeric form. Together these structures span the entire γ-Pcdh ectodomain. The trans -dimer structures reveal determinants of γ-Pcdh isoform-specific homophilic recognition. We identified and structurally mapped cis -dimerization mutations to the C-terminal ectodomain structures. Biophysical studies showed that Pcdh ectodomains from γB-subfamily isoforms formed cis dimers, whereas γA isoforms did not, but both γA and γB isoforms could interact in cis with α-Pcdhs. Together, these data show how interaction specificity is distributed over all domains of the γ-Pcdh trans interface, and suggest that subfamily- or isoform-specific cis -interactions may play a role in the Pcdh-mediated neuronal self-recognition code.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Biophysics, Columbia University, New York, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protocadherin gamma A9537Mus musculusMutation(s): 0
Gene Names: Pcdhga9
UniProt
Find proteins for Q91XX9 (Mus musculus)
Explore Q91XX9
Go to UniProtKB:  Q91XX9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ91XX9
Glycosylation
Glycosylation Sites: 5Go to GlyGen: Q91XX9-1
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
B
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG

Download Ideal Coordinates CCD File
F [auth A]2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
MAN
Query on MAN

Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A]
alpha-D-mannopyranose
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
V [auth A],
W [auth A]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
G [auth A]
H [auth A]
I [auth A]
J [auth A]
K [auth A]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:  0.295 (Depositor), 0.300 (DCC)
  • R-Value Work:  0.241 (Depositor), 0.240 (DCC)
  • R-Value Observed: 0.244 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 191.68α = 90
b = 107.61β = 97.14
c = 49.87γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted NAGClick on this verticalbar to view detailsBest fitted MANClick on this verticalbar to view details

Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM103403
National Institutes of Health/Office of the DirectorUnited StatesOD012351
National Institutes of Health/Office of the DirectorUnited StatesOD021764

Revision History  (Full details and data files)

  • Version 1.0: 2016-10-19
    Type: Initial release
  • Version 1.1: 2016-11-09
    Changes: Database references
  • Version 1.2: 2017-09-20
    Changes: Author supporting evidence, Derived calculations
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2022-03-23
    Changes: Author supporting evidence, Database references, Structure summary
  • Version 2.2: 2024-04-03
    Changes: Data collection, Refinement description
  • Version 2.3: 2024-10-30
    Changes: Structure summary
