5SUX | pdb_00005sux

Crystal Structure of ToxT from Vibrio Cholerae O395 bound to (E)-4-(8-methylnaphthalen-1-yl)but-3-enoic acid

PDB DOI: https://doi.org/10.2210/pdb5SUX/pdb

Classification: TRANSCRIPTION/TRANSCRIPTION INHIBITOR
Organism(s): Vibrio cholerae
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2016-08-04 Released: 2017-04-12
Deposition Author(s): Kull, F.J., Kelley, A.R.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.230 (Depositor), 0.230 (DCC)
R-Value Work:
0.189 (Depositor), 0.192 (DCC)
R-Value Observed:
0.191 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5SUX

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history.

Literature

Crystal Structure of ToxT from Vibrio Cholerae O395 bound to (E)-4-(8-methylnaphthalen-1-yl)but-3-enoic acid

Kull, F.J., Kelley, A.R.

To be published.

Macromolecule Content

Total Structure Weight: 32.71 kDa
Atom Count: 2,311
Modeled Residue Count: 267
Deposited Residue Count: 276
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
AraC family transcriptional regulator	A	276	Vibrio cholerae	Mutation(s): 0 Gene Names: toxT, tcpN, EN12_04130, ERS013198_02000, ERS013199_00625, ERS013200_01425, ERS013202_00629, ERS013206_00617, ERS013207_01424
UniProt
Find proteins for Q7BGC0 (Vibrio cholerae) Explore Q7BGC0 Go to UniProtKB: Q7BGC0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q7BGC0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
70H Query on 70H Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(3E)-4-(8-methylnaphthalen-1-yl)but-3-enoic acid C₁₅ H₁₄ O₂ FALDQPGQWAZNKV-RUDMXATFSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
MES Query on MES Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A]	C [auth A], D [auth A]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.230 (Depositor), 0.230 (DCC)
R-Value Work: 0.189 (Depositor), 0.192 (DCC)
R-Value Observed: 0.191 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.52	α = 90
b = 80.96	β = 90
c = 84.49	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-04-12

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	AI072661

Revision History (Full details and data files)

Version 1.0: 2017-04-12
Type: Initial release
Version 1.1: 2017-08-09
Changes: Database references
Version 1.2: 2017-09-20
Changes: Author supporting evidence
Version 1.3: 2019-12-11
Changes: Author supporting evidence
Version 1.4: 2024-03-06
Changes: Data collection, Database references
