5SMK

PanDDA analysis group deposition of ground-state model of SARS-CoV-2 NSP14

• PDB DOI: https://doi.org/10.2210/pdb5SMK/pdb
• Deposition Group: G_1002231 (ground state) ExploreG_1002231

• Classification: HYDROLASE
• Organism(s): Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2022-03-08 Released: 2022-03-23
• Deposition Author(s): Imprachim, N., Yosaatmadja, Y., von-Delft, F., Bountra, C., Gileadi, O., Newman, J.A.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free: 0.217
• R-Value Work: 0.191
• R-Value Observed: 0.192

Literature

PanDDA analysis group deposition of ground-state model

Imprachim, N., Yosaatmadja, Y., von-Delft, F., Bountra, C., Gileadi, O., Newman, J.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 59.92 kDa
• Atom Count: 4,116
• Modelled Residue Count: 459
• Deposited Residue Count: 523
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Proofreading exoribonuclease nsp14	A [auth D]	523	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.1.13
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	E [auth D], F [auth D]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K
ZN	B [auth D], C [auth D], D	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free: 0.217
• R-Value Work: 0.191
• R-Value Observed: 0.192
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.538	α = 90
b = 68.093	β = 90
c = 138.425	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-03-23
Deposition Author(s): Imprachim, N., Yosaatmadja, Y., von-Delft, F., Bountra, C., Gileadi, O., Newman, J.A.

---

Funding Organization	Location	Grant Number
Not funded	United Kingdom	None

Revision History

• Version 1.0: 2022-03-23
  Type: Initial release

• Version 1.1: 2024-05-22
  Changes: Data collection
