5SJW

CRYSTAL STRUCTURE OF HUMAN PHOSPHODIESTERASE 10 IN COMPLEX WITH C(Nc1ccc2c(c1)nc([nH]2)c3ccccc3)(=O)c4c(Cl)cnn4CC(C)C, micromolar IC50=0.448073

PDB DOI: https://doi.org/10.2210/pdb5SJW/pdb
Deposition Group: G_1002229 ExploreG_1002229

Classification: HYDROLASE/HYDROLASE inhibitor
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-02-01 Released: 2022-10-12
Deposition Author(s): Joseph, C., Benz, J., Flohr, A., Peters, J., Rudolph, M.G.
Funding Organization(s): F. Hoffmann-La Roche

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.207
R-Value Work: 0.172
R-Value Observed: 0.174

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of a human phosphodiesterase 10 complex

Flohr, A., Schlatter, D., Kuhn, B., Rudolph, M.G.

To be published.

Macromolecule Content

Total Structure Weight: 159.71 kDa
Atom Count: 11,279
Modelled Residue Count: 1,252
Deposited Residue Count: 1,372
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
cAMP and cAMP-inhibited cGMP 3',5'-cyclic phosphodiesterase 10A	A, B, C, D	343	Homo sapiens	Mutation(s): 0 Gene Names: PDE10A EC: 3.1.4.17
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y233 (Homo sapiens) Explore Q9Y233 Go to UniProtKB: Q9Y233
PHAROS: Q9Y233 GTEx: ENSG00000112541
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9Y233
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
K9O (Subject of Investigation/LOI) Query on K9O Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain R [auth D] SDF format, chain L [auth B] SDF format, chain O [auth C] MOL2 format, chain I [auth A] MOL2 format, chain R [auth D] MOL2 format, chain L [auth B] MOL2 format, chain O [auth C] mmCIF format, chain I [auth A] mmCIF format, chain R [auth D] mmCIF format, chain L [auth B] mmCIF format, chain O [auth C]	I [auth A], L [auth B], O [auth C], R [auth D]	4-chloro-1-(2-methylpropyl)-N-(2-phenyl-1H-benzimidazol-6-yl)-1H-pyrazole-5-carboxamide C₂₁ H₂₀ Cl N₅ O WUTXTLLQXHZSAP-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain L [auth B] Focus chain O [auth C] Focus chain R [auth D] Interactions & Density Focus chain I [auth A] Focus chain L [auth B] Focus chain O [auth C] Focus chain R [auth D]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain M [auth C] SDF format, chain J [auth B] SDF format, chain P [auth D] MOL2 format, chain E [auth A] MOL2 format, chain M [auth C] MOL2 format, chain J [auth B] MOL2 format, chain P [auth D] mmCIF format, chain E [auth A] mmCIF format, chain M [auth C] mmCIF format, chain J [auth B] mmCIF format, chain P [auth D]	E [auth A], J [auth B], M [auth C], P [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D] Interactions & Density Focus chain E [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
MG Query on MG Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain K [auth B] SDF format, chain N [auth C] SDF format, chain Q [auth D] MOL2 format, chain F [auth A] MOL2 format, chain K [auth B] MOL2 format, chain N [auth C] MOL2 format, chain Q [auth D] mmCIF format, chain F [auth A] mmCIF format, chain K [auth B] mmCIF format, chain N [auth C] mmCIF format, chain Q [auth D]	F [auth A], K [auth B], N [auth C], Q [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain K [auth B] Focus chain N [auth C] Focus chain Q [auth D] Interactions & Density Focus chain F [auth A] Focus chain K [auth B] Focus chain N [auth C] Focus chain Q [auth D]
