5QIO | pdb_00005qio

Covalent fragment group deposition -- Crystal Structure of OUTB2 in complex with P11

• PDB DOI: https://doi.org/10.2210/pdb5QIO/pdb
• Deposition Group: G_1002053 (changed state) ExploreG_1002053

• Classification: Hydrolase/Hydrolase inhibitor
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-08-10 Released: 2019-12-18
• Deposition Author(s): Sethi, R., Douangamath, A., Resnick, E., Bradley, A.R., Collins, P., Brandao-Neto, J., Talon, R., Krojer, T., Bountra, C., Arrowsmith, C.H., Edwards, A., London, N., von Delft, F.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.46 Å
• R-Value Free:
  0.197 (Depositor), 0.200 (DCC)
• R-Value Work:
  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.174 (Depositor)

Literature

Covalent fragment group deposition

Sethi, R., Douangamath, A., Resnick, E., Bradley, A.R., Collins, P., Brandao-Neto, J., Talon, R., Krojer, T., Bountra, C., Arrowsmith, C.H., Edwards, A., London, N., von Delft, F.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 26.61 kDa
• Atom Count: 2,080
• Modelled Residue Count: 225
• Deposited Residue Count: 225
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ubiquitin thioesterase OTUB2	A	225	Homo sapiens	Mutation(s): 0  Gene Names: OTUB2, C14orf137, OTB2, OTU2 EC: 3.4.19.12
UniProt & NIH Common Fund Data Resources
Find proteins for Q96DC9 (Homo sapiens) Explore Q96DC9  Go to UniProtKB:  Q96DC9
PHAROS:  Q96DC9 GTEx:  ENSG00000089723

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
J4Y	C [auth A]	(1S,2S)-N'-(chloroacetyl)-2-phenylcyclopropane-1-carbohydrazide C12 H13 Cl N2 O2 MDZKSIJGAAFPGQ-ZJUUUORDSA-N
UNL	B [auth A]	Unknown ligand MDZKSIJGAAFPGQ-ZJUUUORDSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.46 Å
• R-Value Free:  0.197 (Depositor), 0.200 (DCC)
• R-Value Work:  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.174 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.797	α = 90
b = 58.146	β = 116.25
c = 49.295	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-12-18
Deposition Author(s): Sethi, R., Douangamath, A., Resnick, E., Bradley, A.R., Collins, P., Brandao-Neto, J., Talon, R., Krojer, T., Bountra, C., Arrowsmith, C.H., Edwards, A., London, N., von Delft, F.

Revision History

• Version 1.0: 2019-12-18
  Type: Initial release

• Version 1.1: 2024-03-06
  Changes: Data collection, Database references
