5OVX | pdb_00005ovx

X-Ray Characterization of Striatal-Enriched Protein Tyrosine Phosphatase Inhibitors


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.228 (Depositor), 0.215 (DCC)
  • R-Value Work:
    0.195 (Depositor), 0.174 (DCC)
  • R-Value Observed:
    0.197 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5OVX

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

X-ray Characterization and Structure-Based Optimization of Striatal-Enriched Protein Tyrosine Phosphatase Inhibitors.

Witten, M.R.Wissler, L.Snow, M.Geschwindner, S.Read, J.A.Brandon, N.J.Nairn, A.C.Lombroso, P.J.Kack, H.Ellman, J.A.

(2017) J Med Chem 60: 9299-9319

  • DOI: https://doi.org/10.1021/acs.jmedchem.7b01292
  • Primary Citation Related Structures:
    5OVR, 5OVX, 5OW1

  • PubMed Abstract:

    Excessive activity of striatal-enriched protein tyrosine phosphatase (STEP) in the brain has been detected in numerous neuropsychiatric disorders including Alzheimer's disease. Notably, knockdown of STEP in an Alzheimer mouse model effected an increase in the phosphorylation levels of downstream STEP substrates and a significant reversal in the observed cognitive and memory deficits. These data point to the promising potential of STEP as a target for drug discovery in Alzheimer's treatment. We previously reported a substrate-based approach to the development of low molecular weight STEP inhibitors with K i values as low as 7.8 μM. Herein, we disclose the first X-ray crystal structures of inhibitors bound to STEP and the surprising finding that they occupy noncoincident binding sites. Moreover, we utilize this structural information to optimize the inhibitor structure to achieve a K i of 110 nM, with 15-60-fold selectivity across a series of phosphatases.


  • Organizational Affiliation
    • Department of Chemistry, Yale University , New Haven, Connecticut 06520, United States.

Macromolecule Content

  • Total Structure Weight: 35.66 kDa
  • Atom Count: 2,617
  • Modeled Residue Count: 287
  • Deposited Residue Count: 305
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Tyrosine-protein phosphatase non-receptor type 5305Homo sapiensMutation(s): 0
Gene Names: PTPN5
EC: 3.1.3.48
UniProt & NIH Common Fund Data Resources
Find proteins for P54829 (Homo sapiens)
Explore P54829
Go to UniProtKB:  P54829
PHAROS:  P54829
GTEx:  ENSG00000110786
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP54829
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
AY5

Query on AY5



Download:Ideal Coordinates CCD File
B [auth A][(~{S})-[4-[3-[(~{S})-(3,4-dichlorophenyl)-oxidanyl-methyl]phenyl]phenyl]-oxidanyl-methyl]phosphonic acid
C20 H17 Cl2 O5 P
KYNFSOSPDJUFDE-PMACEKPBSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
CSO
Query on CSO
A
L-PEPTIDE LINKINGC3 H7 N O3 SCYS

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.228 (Depositor), 0.215 (DCC)
  • R-Value Work:  0.195 (Depositor), 0.174 (DCC)
  • R-Value Observed: 0.197 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 52.117α = 90
b = 64.124β = 90
c = 100.338γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
BUSTERrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-11-22
    Type: Initial release
  • Version 1.1: 2017-11-29
    Changes: Database references
  • Version 1.2: 2024-01-17
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-11-13
    Changes: Structure summary
