5NPA | pdb_00005npa

Solution structure of Drosophila melanogaster Loquacious dsRBD2


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 5000
  • Conformers Submitted: 10
  • Selection Criteria: Rosetta score

wwPDB Validation 3D Report Full Report

Validation slider image for 5NPA

This is version 1.5 of the entry. See complete history

Literature

Molecular basis for asymmetry sensing of siRNAs by the Drosophila Loqs-PD/Dcr-2 complex in RNA interference.

Tants, J.N.Fesser, S.Kern, T.Stehle, R.Geerlof, A.Wunderlich, C.Juen, M.Hartlmuller, C.Bottcher, R.Kunzelmann, S.Lange, O.Kreutz, C.Forstemann, K.Sattler, M.

(2017) Nucleic Acids Res 45: 12536-12550

  • DOI: https://doi.org/10.1093/nar/gkx886
  • Primary Citation Related Structures:
    5NPA, 5NPG

  • PubMed Abstract:

    RNA interference defends against RNA viruses and retro-elements within an organism's genome. It is triggered by duplex siRNAs, of which one strand is selected to confer sequence-specificity to the RNA induced silencing complex (RISC). In Drosophila, Dicer-2 (Dcr-2) and the double-stranded RNA binding domain (dsRBD) protein R2D2 form the RISC loading complex (RLC) and select one strand of exogenous siRNAs according to the relative thermodynamic stability of base-pairing at either end. Through genome editing we demonstrate that Loqs-PD, the Drosophila homolog of human TAR RNA binding protein (TRBP) and a paralog of R2D2, forms an alternative RLC with Dcr-2 that is required for strand choice of endogenous siRNAs in S2 cells. Two canonical dsRBDs in Loqs-PD bind to siRNAs with enhanced affinity compared to miRNA/miRNA* duplexes. Structural analysis, NMR and biophysical experiments indicate that the Loqs-PD dsRBDs can slide along the RNA duplex to the ends of the siRNA. A moderate but notable binding preference for the thermodynamically more stable siRNA end by Loqs-PD alone is greatly amplified in complex with Dcr-2 to initiate strand discrimination by asymmetry sensing in the RLC.


  • Organizational Affiliation
    • Institute of Structural Biology, Helmholtz Zentrum München, 85764 Neuherberg, Germany.

Macromolecule Content

  • Total Structure Weight: 8.54 kDa
  • Atom Count: 560
  • Modeled Residue Count: 67
  • Deposited Residue Count: 72
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Loquacious72Drosophila melanogasterMutation(s): 0
Gene Names:
UniProt
Find proteins for Q9VJY9 (Drosophila melanogaster)
Explore Q9VJY9
Go to UniProtKB:  Q9VJY9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9VJY9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 5000
  • Conformers Submitted: 10
  • Selection Criteria: Rosetta score

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2017-10-04
    Type: Initial release
  • Version 1.1: 2017-10-11
    Changes: Database references
  • Version 1.2: 2017-11-01
    Changes: Database references
  • Version 1.3: 2017-12-13
    Changes: Database references
  • Version 1.4: 2019-05-08
    Changes: Data collection
  • Version 1.5: 2024-05-15
    Changes: Data collection, Database references
