5NNS | pdb_00005nns

Crystal structure of HiLPMO9B


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.251 (Depositor), 0.253 (DCC)
  • R-Value Work:
    0.200 (Depositor), 0.207 (DCC)
  • R-Value Observed:
    0.203 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5NNS

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Structural and molecular dynamics studies of a C1-oxidizing lytic polysaccharide monooxygenase from Heterobasidion irregulare reveal amino acids important for substrate recognition.

Liu, B.Kognole, A.A.Wu, M.Westereng, B.Crowley, M.F.Kim, S.Dimarogona, M.Payne, C.M.Sandgren, M.

(2018) FEBS J 285: 2225-2242

  • DOI: https://doi.org/10.1111/febs.14472
  • Primary Citation Related Structures:
    5NNS

  • PubMed Abstract:

    Lytic polysaccharide monooxygenases (LPMOs) are a group of recently discovered enzymes that play important roles in the decomposition of recalcitrant polysaccharides. Here, we report the biochemical, structural, and computational characterization of an LPMO from the white-rot fungus Heterobasidion irregulare (HiLPMO9B). This enzyme oxidizes cellulose at the C1 carbon of glycosidic linkages. The crystal structure of HiLPMO9B was determined at 2.1 Å resolution using X-ray crystallography. Unlike the majority of the currently available C1-specific LPMO structures, the HiLPMO9B structure contains an extended L2 loop, connecting β-strands β2 and β3 of the β-sandwich structure. Molecular dynamics (MD) simulations suggest roles for both aromatic and acidic residues in the substrate binding of HiLPMO9B, with the main contribution from the residues located on the extended region of the L2 loop (Tyr20) and the LC loop (Asp205, Tyr207, and Glu210). Asp205 and Glu210 were found to be involved in the hydrogen bonding with the hydroxyl group of the C6 carbon of glucose moieties directly or via a water molecule. Two different binding orientations were observed over the course of the MD simulations. In each orientation, the active-site copper of this LPMO preferentially skewed toward the pyranose C1 of the glycosidic linkage over the targeted glycosidic bond. This study provides additional insight into cellulose binding by C1-specific LPMOs, giving a molecular-level picture of active site substrate interactions. The atomic coordinates and structure factors for HiLPMO9B have been deposited in the Protein Data Bank with accession code 5NNS.


  • Organizational Affiliation
    • Department of Molecular Sciences, Swedish University of Agricultural Sciences, Uppsala, Sweden.

Macromolecule Content

  • Total Structure Weight: 50.68 kDa
  • Atom Count: 3,854
  • Modeled Residue Count: 450
  • Deposited Residue Count: 450
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Glycosyl hydrolase family 61, 2 protein
A, B
225Heterobasidion irregulare TC 32-1Mutation(s): 0
Gene Names: GH61BHETIRDRAFT_166613
EC: 1.14.99.56
UniProt
Find proteins for W4KMP1 (Heterobasidion irregulare (strain TC 32-1))
Explore W4KMP1
Go to UniProtKB:  W4KMP1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupW4KMP1
Glycosylation
Glycosylation Sites: 2
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAG

Query on NAG



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
Q [auth B],
R [auth B]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
AA [auth B]
BA [auth B]
F [auth A]
G [auth A]
H [auth A]
AA [auth B],
BA [auth B],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
T [auth B],
U [auth B],
V [auth B],
W [auth B],
X [auth B],
Y [auth B],
Z [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
AKR

Query on AKR



Download:Ideal Coordinates CCD File
CA [auth B],
DA [auth B],
EA [auth B],
N [auth A],
O [auth A]
ACRYLIC ACID
C3 H4 O2
NIXOWILDQLNWCW-UHFFFAOYSA-N
CU

Query on CU



Download:Ideal Coordinates CCD File
E [auth A],
S [auth B]
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
P [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.251 (Depositor), 0.253 (DCC)
  • R-Value Work:  0.200 (Depositor), 0.207 (DCC)
  • R-Value Observed: 0.203 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.695α = 90
b = 46.375β = 103.23
c = 86.492γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
VinnovaSweden--

Revision History  (Full details and data files)

  • Version 1.0: 2018-05-16
    Type: Initial release
  • Version 1.1: 2018-12-05
    Changes: Data collection, Database references
  • Version 1.2: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Author supporting evidence, Data collection, Derived calculations, Refinement description, Structure summary
  • Version 1.3: 2024-01-17
    Changes: Data collection, Database references, Refinement description, Structure summary
  • Version 1.4: 2024-11-20
    Changes: Structure summary
