5NFO | pdb_00005nfo

Human JMJD7 in complex with Mn and 2OG in the P21212 form

PDB DOI: https://doi.org/10.2210/pdb5NFO/pdb

Classification: OXIDOREDUCTASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2017-03-14 Released: 2018-03-14
Deposition Author(s): Chowdhury, R., Markolovic, S., Schofield, C.J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.17 Å
R-Value Free:
0.189 (Depositor), 0.191 (DCC)
R-Value Work:
0.171 (Depositor), 0.193 (DCC)
R-Value Observed:
0.173 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

(3S)-Lysyl hydroxylation of TRAFAC GTPases is catalyzed by the human Jumonji-C oxygenase JMJD7.

Markolovic, S., Zhuang, Q., Wilkins, S.E., Eaton, C., Katz, M.J., Smith, H.E., Lesniak, R.K., Hall, C., Struwe, W.B., Konietzny, R., Davis, S., Yang, M., Ge, W., Benesch, J.L., Kessler, B.M., Ratcliffe, P.J., Cockman, M.E., Fischer, R., Wappner, P., Chowdhury, R., Coleman, M.L., Schofield, C.J.

To be published.

Macromolecule Content

Total Structure Weight: 76.99 kDa
Atom Count: 5,452
Modeled Residue Count: 635
Deposited Residue Count: 670
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
JmjC domain-containing protein 7	A, B	335	Homo sapiens	Mutation(s): 1 Gene Names: JMJD7 EC: 3.4 (UniProt), 1.14.11.63 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P0C870 (Homo sapiens) Explore P0C870 Go to UniProtKB: P0C870
GTEx: ENSG00000243789
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0C870
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
AKG Query on AKG Download:Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain D [auth A] MOL2 format, chain J [auth B] MOL2 format, chain D [auth A] mmCIF format, chain J [auth B] mmCIF format, chain D [auth A]	D [auth A], J [auth B]	2-OXOGLUTARIC ACID C₅ H₆ O₅ KPGXRSRHYNQIFN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain J [auth B] Interactions & Density Focus chain D [auth A] Focus chain J [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] K [auth B] L [auth B] E [auth A], F [auth A], G [auth A], K [auth B], L [auth B], M [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]
NO3 Query on NO3 Download:Ideal Coordinates CCD File SDF format, chain N [auth B] SDF format, chain H [auth A] MOL2 format, chain N [auth B] MOL2 format, chain H [auth A] mmCIF format, chain N [auth B] mmCIF format, chain H [auth A]	H [auth A], N [auth B]	NITRATE ION N O₃ NHNBFGGVMKEFGY-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain N [auth B] Interactions & Density Focus chain H [auth A] Focus chain N [auth B]
MN Query on MN Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain C [auth A] MOL2 format, chain I [auth B] MOL2 format, chain C [auth A] mmCIF format, chain I [auth B] mmCIF format, chain C [auth A]	C [auth A], I [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain I [auth B] Interactions & Density Focus chain C [auth A] Focus chain I [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.17 Å
R-Value Free: 0.189 (Depositor), 0.191 (DCC)
R-Value Work: 0.171 (Depositor), 0.193 (DCC)
R-Value Observed: 0.173 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 137.315	α = 90
b = 61.02	β = 90
c = 86.055	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2018-03-14

Deposition Author(s):

Chowdhury, R.

Markolovic, S.

Schofield, C.J.

Revision History (Full details and data files)

Version 1.0: 2018-03-14
Type: Initial release
Version 1.1: 2019-06-12
Changes: Data collection, Structure summary
Version 1.2: 2024-01-17
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.3: 2024-11-20
Changes: Structure summary
