5LO8 | pdb_00005lo8

The C2B domain of Rabphilin 3A in complex with PI(4,5)P2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.265 (Depositor), 0.246 (DCC)
  • R-Value Work:
    0.252 (Depositor)
  • R-Value Observed:
    0.271 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5LO8

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Structural characterization of the Rabphilin-3A-SNAP25 interaction.

Ferrer-Orta, C.Perez-Sanchez, M.D.Coronado-Parra, T.Silva, C.Lopez-Martinez, D.Baltanas-Copado, J.Gomez-Fernandez, J.C.Corbalan-Garcia, S.Verdaguer, N.

(2017) Proc Natl Acad Sci U S A 114: E5343-E5351

  • DOI: https://doi.org/10.1073/pnas.1702542114
  • Primary Citation Related Structures:
    5LO8, 5LOB, 5LOW

  • PubMed Abstract:

    Membrane fusion is essential in a myriad of eukaryotic cell biological processes, including the synaptic transmission. Rabphilin-3A is a membrane trafficking protein involved in the calcium-dependent regulation of secretory vesicle exocytosis in neurons and neuroendocrine cells, but the underlying mechanism remains poorly understood. Here, we report the crystal structures and biochemical analyses of Rabphilin-3A C2B-SNAP25 and C2B-phosphatidylinositol 4,5-bisphosphate (PIP 2 ) complexes, revealing how Rabphilin-3A C2 domains operate in cooperation with PIP 2 /Ca 2+ and SNAP25 to bind the plasma membrane, adopting a conformation compatible to interact with the complete SNARE complex. Comparisons with the synaptotagmin1-SNARE show that both proteins contact the same SNAP25 surface, but Rabphilin-3A uses a unique structural element. Data obtained here suggest a model to explain the Ca 2+ -dependent fusion process by membrane bending with a myriad of variations depending on the properties of the C2 domain-bearing protein, shedding light to understand the fine-tuning control of the different vesicle fusion events.


  • Organizational Affiliation
    • Structural Biology Unit, Institut de Biologia Molecular de Barcelona, Consejo Superior de Investigaciones Cientificas, 08028 Barcelona, Spain; cfocri@ibmb.csic.es senena@um.es nvmcri@ibmb.csic.es.

Macromolecule Content

  • Total Structure Weight: 39.55 kDa
  • Atom Count: 2,465
  • Modeled Residue Count: 282
  • Deposited Residue Count: 324
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Rabphilin-3A
A, B
162Rattus norvegicusMutation(s): 0
Gene Names: Rph3a
UniProt
Find proteins for P47709 (Rattus norvegicus)
Explore P47709
Go to UniProtKB:  P47709
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47709
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PIO

Query on PIO



Download:Ideal Coordinates CCD File
J [auth A],
P [auth B]
[(2R)-2-octanoyloxy-3-[oxidanyl-[(1R,2R,3S,4R,5R,6S)-2,3,6-tris(oxidanyl)-4,5-diphosphonooxy-cyclohexyl]oxy-phosphoryl]oxy-propyl] octanoate
C25 H49 O19 P3
XLNCEHRXXWQMPK-MJUMVPIBSA-N
SO4

Query on SO4



Download:Ideal Coordinates CCD File
I [auth A]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
E [auth A]
F [auth A]
G [auth A]
H [auth A]
M [auth B]
E [auth A],
F [auth A],
G [auth A],
H [auth A],
M [auth B],
N [auth B],
O [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CA

Query on CA



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
K [auth B],
L [auth B]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.265 (Depositor), 0.246 (DCC)
  • R-Value Work:  0.252 (Depositor)
  • R-Value Observed: 0.271 (Depositor)
Space Group: P 4
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.52α = 90
b = 92.52β = 90
c = 40.02γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
iMOSFLMdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-06-21
    Type: Initial release
  • Version 1.1: 2017-12-06
    Changes: Database references
  • Version 1.2: 2024-01-10
    Changes: Data collection, Database references, Derived calculations, Refinement description
