5KWR | pdb_00005kwr

Crystal structure of rat Cerebellin-1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.79 Å
  • R-Value Free:
    0.189 (Depositor), 0.191 (DCC)
  • R-Value Work:
    0.160 (Depositor), 0.160 (DCC)
  • R-Value Observed:
    0.163 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5KWR

This is version 2.2 of the entry. See complete history

Literature

Conformational Plasticity in the Transsynaptic Neurexin-Cerebellin-Glutamate Receptor Adhesion Complex.

Cheng, S.Seven, A.B.Wang, J.Skiniotis, G.Ozkan, E.

(2016) Structure 24: 2163-2173

  • DOI: https://doi.org/10.1016/j.str.2016.11.004
  • Primary Citation Related Structures:
    5KWR, 5L2E

  • PubMed Abstract:

    Synaptic specificity is a defining property of neural networks. In the cerebellum, synapses between parallel fiber neurons and Purkinje cells are specified by the simultaneous interactions of secreted protein cerebellin with pre-synaptic neurexin and post-synaptic delta-type glutamate receptors (GluD). Here, we determined the crystal structures of the trimeric C1q-like domain of rat cerebellin-1, and the first complete ectodomain of a GluD, rat GluD2. Cerebellin binds to the LNS6 domain of α- and β-neurexin-1 through a high-affinity interaction that involves its highly flexible N-terminal domain. In contrast, we show that the interaction of cerebellin with isolated GluD2 ectodomain is low affinity, which is not simply an outcome of lost avidity when compared with binding with a tetrameric full-length receptor. Rather, high-affinity capture of cerebellin by post-synaptic terminals is likely controlled by long-distance regulation within this transsynaptic complex. Altogether, our results suggest unusual conformational flexibility within all components of the complex.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biology, University of Chicago, Chicago, IL 60637, USA.

Macromolecule Content

  • Total Structure Weight: 16.78 kDa
  • Atom Count: 1,238
  • Modeled Residue Count: 139
  • Deposited Residue Count: 143
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Cerebellin-1143Rattus norvegicusMutation(s): 0
Gene Names: Cbln1
UniProt
Find proteins for P63182 (Rattus norvegicus)
Explore P63182
Go to UniProtKB:  P63182
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP63182
Glycosylation
Glycosylation Sites: 1Go to GlyGen: P63182-1
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-L-fucopyranose-(1-3)-[2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)]2-acetamido-2-deoxy-beta-D-glucopyranose
B
3N-Glycosylation
Glycosylation Resources
GlyTouCan: G11971MR
GlyCosmos: G11971MR
GlyGen: G11971MR

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.79 Å
  • R-Value Free:  0.189 (Depositor), 0.191 (DCC)
  • R-Value Work:  0.160 (Depositor), 0.160 (DCC)
  • R-Value Observed: 0.163 (Depositor)
Space Group: P 6
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 82.74α = 90
b = 82.74β = 90
c = 50.37γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Klingenstein FoundationUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2016-08-03
    Type: Initial release
  • Version 1.1: 2016-12-28
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2023-10-04
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
  • Version 2.2: 2024-10-23
    Changes: Structure summary
