5KW1

Crystal Structure of the Two Tandem RRM Domains of PUF60 Bound to a Modified AdML Pre-mRNA 3' Splice Site Analogue


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.220

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 2.2 of the entry. See complete history


Literature

Unraveling the mechanism of recognition of the 3' splice site of the adenovirus major late promoter intron by the alternative splicing factor PUF60.

Hsiao, H.T.Crichlow, G.V.Murphy, J.W.Folta-Stogniew, E.J.Lolis, E.J.Braddock, D.T.

(2020) PLoS One 15: e0242725-e0242725

  • DOI: https://doi.org/10.1371/journal.pone.0242725
  • Primary Citation of Related Structures:
    5KVY, 5KW1, 5KW6, 5KWQ

  • PubMed Abstract:

    Pre-mRNA splicing is critical for achieving required amounts of a transcript at a given time and for regulating production of encoded protein. A given pre-mRNA may be spliced in many ways, or not at all, giving rise to multiple gene products. Numerous splicing factors are recruited to pre-mRNA splice sites to ensure proper splicing. One such factor, the 60 kDa poly(U)-binding splicing factor (PUF60), is recruited to sites that are not always spliced, but rather function as alternative splice sites. In this study, we characterized the interaction of PUF60 with a splice site from the adenovirus major late promoter (the AdML 3' splice site, AdML3'). We found that the PUF60-AdML3' dissociation constants are in the micromolar range, with the binding affinity predominantly provided by PUF60's two central RNA recognition motifs (RRMs). A 1.95 Å crystal structure of the two PUF60 RRMs in complex with AdML3' revealed a dimeric organization placing two stretches of nucleic acid tracts in opposing directionalities, which can cause looping of nucleic acid and explain how PUF60 affects pre-mRNA geometry to effect splicing. Solution characterization of this complex by light-scattering and UV/Vis spectroscopy suggested a potential 2:1 (PUF602:AdML3') stoichiometry, consistent with the crystal structure. This work defines the sequence specificity of the alternative splicing factor PUF60 at the pre-mRNA 3' splice site. Our observations suggest that control of pre-mRNA directionality is important in the early stage of spliceosome assembly, and advance our understanding of the molecular mechanism by which alternative and constitutive splicing factors differentiate among 3' splice sites.


  • Organizational Affiliation

    Department of Pathology, Yale University School of Medicine, New Haven, Connecticut, United States of America.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Poly(U)-binding-splicing factor PUF60
A, B
216Homo sapiensMutation(s): 3
Gene Names: PUF60FIRROBPISIAHBP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UHX1 (Homo sapiens)
Explore Q9UHX1
Go to UniProtKB:  Q9UHX1
PHAROS:  Q9UHX1
GTEx:  ENSG00000179950
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UHX1
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by: 3D Structure
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA/RNA (30-MER)30unidentified adenovirus
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CL
Query on CL

Download Ideal Coordinates CCD File
D [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.220
  • Space Group: P 31
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.428α = 90
b = 62.428β = 90
c = 83.313γ = 120
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
American Cancer SocietyUnited StatesRSG-0-222-01

Revision History  (Full details and data files)

  • Version 1.0: 2017-08-23
    Type: Initial release
  • Version 1.1: 2020-12-09
    Changes: Database references
  • Version 2.0: 2020-12-16
    Changes: Advisory, Atomic model, Database references, Experimental preparation, Structure summary
  • Version 2.1: 2022-06-08
    Changes: Database references
  • Version 2.2: 2023-10-04
    Changes: Data collection, Refinement description
