5KTJ | pdb_00005ktj

Crystal structure of Pistol, a class of self-cleaving ribozyme

  • Classification: RNA
  • Organism(s): metagenome
  • Expression System: metagenome
  • Mutation(s): No

  • Deposited: 2016-07-11 Released: 2016-10-05
  • Deposition Author(s): Nguyen, L.A., Wang, J., Steitz, T.A.
  • Funding Organization(s): Howard Hughes Medical Institute (HHMI), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.97 Å
  • R-Value Free:
    0.257 (Depositor), 0.239 (DCC)
  • R-Value Work:
    0.196 (Depositor)
  • R-Value Observed:
    0.198 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5KTJ

This is version 1.5 of the entry. See complete history

Literature

Crystal structure of Pistol, a class of self-cleaving ribozyme.

Nguyen, L.A.Wang, J.Steitz, T.A.

(2017) Proc Natl Acad Sci U S A 114: 1021-1026

  • DOI: https://doi.org/10.1073/pnas.1611191114
  • Primary Citation Related Structures:
    5KTJ

  • PubMed Abstract:

    Small self-cleaving ribozymes have been discovered in all evolutionary domains of life. They can catalyze site-specific RNA cleavage, and as a result, they have relevance in gene regulation. Comparative genomic analysis has led to the discovery of a new class of small self-cleaving ribozymes named Pistol. We report the crystal structure of Pistol at 2.97-Å resolution. Our results suggest that the Pistol ribozyme self-cleavage mechanism likely uses a guanine base in the active site pocket to carry out the phosphoester transfer reaction. The guanine G40 is in close proximity to serve as the general base for activating the nucleophile by deprotonating the 2'-hydroxyl to initiate the reaction (phosphoester transfer). Furthermore, G40 can also establish hydrogen bonding interactions with the nonbridging oxygen of the scissile phosphate. The proximity of G32 to the O5' leaving group suggests that G32 may putatively serve as the general acid. The RNA structure of Pistol also contains A-minor interactions, which seem to be important to maintain its tertiary structure and compact fold. Our findings expand the repertoire of ribozyme structures and highlight the conserved evolutionary mechanism used by ribozymes for catalysis.


  • Organizational Affiliation
    • Department of Molecular Biochemistry and Biophysics, Yale University, New Haven, CT 06520.

Macromolecule Content

  • Total Structure Weight: 45.68 kDa
  • Atom Count: 2,966
  • Modeled Residue Count: 130
  • Deposited Residue Count: 130
  • Unique nucleic acid chains: 2

Macromolecules

Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 1
MoleculeChains LengthOrganismImage
Pistol (50-MER)
A, C
50metagenome
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
RNA (5'-R(*UP*CP*UP*GP*CP*UP*CP*UP*CP*GP*UP*CP*CP*AP*A)-3')
B, D
15metagenome
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NCO

Query on NCO



Download:Ideal Coordinates CCD File
GA [auth C]
HA [auth C]
IA [auth C]
N [auth A]
O [auth A]
GA [auth C],
HA [auth C],
IA [auth C],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
QA [auth D],
R [auth A],
X [auth B]
COBALT HEXAMMINE(III)
Co H18 N6
DYLMFCCYOUSRTK-UHFFFAOYSA-N
SM

Query on SM



Download:Ideal Coordinates CCD File
AA [auth C]
BA [auth C]
E [auth A]
F [auth A]
G [auth A]
AA [auth C],
BA [auth C],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
PA [auth D],
Y [auth C],
Z [auth C]
SAMARIUM (III) ION
Sm
DOSGOCSVHPUUIA-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
CA [auth C]
DA [auth C]
EA [auth C]
FA [auth C]
J [auth A]
CA [auth C],
DA [auth C],
EA [auth C],
FA [auth C],
J [auth A],
JA [auth C],
K [auth A],
KA [auth C],
L [auth A],
LA [auth C],
M [auth A],
MA [auth C],
NA [auth C],
OA [auth C],
S [auth A],
T [auth A],
U [auth A],
V [auth A],
W [auth A]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.97 Å
  • R-Value Free:  0.257 (Depositor), 0.239 (DCC)
  • R-Value Work:  0.196 (Depositor)
  • R-Value Observed: 0.198 (Depositor)
Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.19α = 90
b = 85.19β = 90
c = 256.54γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
SHELXDEphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Howard Hughes Medical Institute (HHMI)United States--
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM022778
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United States5F32AI114095-02

Revision History  (Full details and data files)

  • Version 1.0: 2016-10-05
    Type: Initial release
  • Version 1.1: 2017-01-18
    Changes: Database references
  • Version 1.2: 2017-02-01
    Changes: Database references, Structure summary
  • Version 1.3: 2017-02-15
    Changes: Database references
  • Version 1.4: 2019-11-20
    Changes: Author supporting evidence
  • Version 1.5: 2024-03-06
    Changes: Data collection, Database references, Derived calculations
