5IR3 | pdb_00005ir3

Crystal structure of the recombinant highest fibrillogenic natural mutant (obtained from patient AR) derived from lambda 6 light chain variable domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:
    0.207 (Depositor), 0.204 (DCC)
  • R-Value Work:
    0.174 (Depositor), 0.176 (DCC)
  • R-Value Observed:
    0.176 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5IR3

This is version 1.4 of the entry. See complete history

Literature

Stabilizing an amyloidogenic lambda 6 light chain variable domain.

Luna-Martinez, O.D.Hernandez-Santoyo, A.Villalba-Velazquez, M.I.Sanchez-Alcala, R.Fernandez-Velasco, D.A.Becerril, B.

(2017) FEBS J 284: 3702-3717

  • DOI: https://doi.org/10.1111/febs.14265
  • Primary Citation Related Structures:
    5IR3

  • PubMed Abstract:

    Light chain amyloidosis is a lethal disease where vital organs are damaged by the fibrillar aggregation of monoclonal light chains. λ6a is an immunoglobulin light chain encoded by the germ-line gene segment implicated in this disease. AR is a patient-derived germ-line variant with a markedly low thermodynamic stability and prone to form fibrils in vitro in less than an hour. Here, we sought to stabilize this domain by mutating some residues back to the germ-line sequence, and the most stabilizing mutations were the single-mutant AR-F21I and the double-mutant AR-F21/IV104L, both located in the hydrophobic core. While mutation Arg25Gly in 6aJL2 destabilized the domain, mutating Gly25 back to arginine in AR did not contribute to stabilization as expected. Crystallographic structures of AR and 6a-R25G were generated to explain this discrepancy. Finally, 6a-R25G crystals revealed an octameric assembly which was emulated into 6aJL2 and AR crystals by replicating their structural parameters and suggesting a common assembly pattern. The atomic coordinates and structure factors have been deposited in the Protein Data Bank under the accession numbers 5IR3 and 5C9K.


  • Organizational Affiliation
    • Departamento de Medicina Molecular y Bioprocesos, Instituto de Biotecnología, Universidad Nacional Autónoma de México, Cuernavaca, Mexico.

Macromolecule Content

  • Total Structure Weight: 11.99 kDa
  • Atom Count: 1,043
  • Modeled Residue Count: 111
  • Deposited Residue Count: 112
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ig lambda chain V-VI region AR112Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P01721 (Homo sapiens)
Explore P01721
Go to UniProtKB:  P01721
PHAROS:  P01721
GTEx:  ENSG00000211640
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01721
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ACT

Query on ACT



Download:Ideal Coordinates CCD File
B [auth A]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:  0.207 (Depositor), 0.204 (DCC)
  • R-Value Work:  0.174 (Depositor), 0.176 (DCC)
  • R-Value Observed: 0.176 (Depositor)
Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.121α = 90
b = 71.121β = 90
c = 96.453γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-06-14
    Type: Initial release
  • Version 1.1: 2017-09-27
    Changes: Database references
  • Version 1.2: 2017-11-22
    Changes: Database references
  • Version 1.3: 2023-09-27
    Changes: Data collection, Database references, Refinement description
  • Version 1.4: 2024-11-06
    Changes: Structure summary
