5I1P | pdb_00005i1p

Villin headpiece subdomain with a Lys30 to beta-3-homolysine substitution


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.40 Å
  • R-Value Free:
    0.235 (Depositor), 0.226 (DCC)
  • R-Value Work:
    0.210 (Depositor), 0.197 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5I1P

This is version 2.0 of the entry. See complete history

Literature

Effects of Single alpha-to-beta Residue Replacements on Structure and Stability in a Small Protein: Insights from Quasiracemic Crystallization.

Kreitler, D.F.Mortenson, D.E.Forest, K.T.Gellman, S.H.

(2016) J Am Chem Soc 138: 6498-6505

  • DOI: https://doi.org/10.1021/jacs.6b01454
  • Primary Citation Related Structures:
    5I1N, 5I1O, 5I1P, 5I1S

  • PubMed Abstract:

    Synthetic peptides that contain backbone modifications but nevertheless adopt folded structures similar to those of natural polypeptides are of fundamental interest and may provide a basis for biomedical applications. Such molecules can, for example, mimic the ability of natural prototypes to bind to specific target macromolecules but resist degradation by proteases. We have previously shown that oligomers containing mixtures of α- and β-amino acid residues ("α/β-peptides") can mimic the α-helix secondary structure, and that properly designed α/β-peptides can bind to proteins that evolved to bind to α-helical partners. Here we report fundamental studies that support the long-range goal of extending the α/β approach to tertiary structures. We have evaluated the impact of single α → β modifications on the structure and stability of the small and well-studied villin headpiece subdomain (VHP). The native state of this 35-residue polypeptide contains several α-helical segments packed around a small hydrophobic core. We examined α → β substitution at four solvent-exposed positions, Asn19, Trp23, Gln26 and Lys30. In each case, both the β(3) homologue of the natural α residue and a cyclic β residue were evaluated. All α → β(3) substitutions caused significant destabilization of the tertiary structure as measured by variable-temperature circular dichroism, although at some of these positions, replacing the β(3) residue with a cyclic β residue led to improved stability. Atomic-resolution structures of four VHP analogues were obtained via quasiracemic crystallization. These findings contribute to a fundamental α/β-peptide knowledge-base by confirming that β(3)-amino acid residues can serve as effective structural mimics of homologous α-amino acid residues within a natural tertiary fold, which should support rational design of functional α/β analogues of natural poly-α-peptides.


  • Organizational Affiliation
    • Department of Chemistry and ‡Department of Bacteriology, University of Wisconsin-Madison , Madison, Wisconsin 53706, United States.

Macromolecule Content

  • Total Structure Weight: 32.88 kDa
  • Atom Count: 2,449
  • Modeled Residue Count: 277
  • Deposited Residue Count: 280
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Villin-1
A, B, C, D
35Gallus gallusMutation(s): 1
UniProt
Find proteins for P02640 (Gallus gallus)
Explore P02640
Go to UniProtKB:  P02640
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02640
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
D-Villin headpiece subdomain
E, F, G, H
35synthetic constructMutation(s): 0

Small Molecules

Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
B3K
Query on B3K
A, B, C, D
L-PEPTIDE LINKINGC7 H16 N2 O2LYS
DAL
Query on DAL
E, F, G, H
D-PEPTIDE LINKINGC3 H7 N O2

--

DAR
Query on DAR
E, F, G, H
D-PEPTIDE LINKINGC6 H15 N4 O2

--

DAS
Query on DAS
E, F, G, H
D-PEPTIDE LINKINGC4 H7 N O4

--

DGL
Query on DGL
E, F, G, H
D-PEPTIDE LINKINGC5 H9 N O4

--

DGN
Query on DGN
E, F, G, H
D-PEPTIDE LINKINGC5 H10 N2 O3

--

DHI
Query on DHI
E, F, G, H
D-PEPTIDE LINKINGC6 H10 N3 O2

--

DLE
Query on DLE
E, F, G, H
D-PEPTIDE LINKINGC6 H13 N O2

--

DLY
Query on DLY
E, F, G, H
D-PEPTIDE LINKINGC6 H14 N2 O2

--

DPN
Query on DPN
E, F, G, H
D-PEPTIDE LINKINGC9 H11 N O2

--

DPR
Query on DPR
E, F, G, H
D-PEPTIDE LINKINGC5 H9 N O2

--

DSG
Query on DSG
E, F, G, H
D-PEPTIDE LINKINGC4 H8 N2 O3

--

DSN
Query on DSN
E, F, G, H
D-PEPTIDE LINKINGC3 H7 N O3

--

DTH
Query on DTH
E, F, G, H
D-PEPTIDE LINKINGC4 H9 N O3

--

DTR
Query on DTR
E, F, G, H
D-PEPTIDE LINKINGC11 H12 N2 O2

--

DVA
Query on DVA
E, F, G, H
D-PEPTIDE LINKINGC5 H11 N O2

--

MED
Query on MED
E, F, G, H
D-PEPTIDE LINKINGC5 H11 N O2 S

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.40 Å
  • R-Value Free:  0.235 (Depositor), 0.226 (DCC)
  • R-Value Work:  0.210 (Depositor), 0.197 (DCC)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 24.57α = 96.45
b = 40.6β = 90.66
c = 59.02γ = 95.37
Software Package:
Software NamePurpose
PHENIXrefinement
XSCALEdata scaling
PHASERphasing
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United StatesMCB 1518160
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesT32 GM00839
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM061238
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesT32 GM08293

Revision History  (Full details and data files)

  • Version 1.0: 2016-05-25
    Type: Initial release
  • Version 1.1: 2016-06-08
    Changes: Database references
  • Version 1.2: 2016-06-15
    Changes: Refinement description
  • Version 1.3: 2016-07-13
    Changes: Refinement description
  • Version 1.4: 2017-09-20
    Changes: Author supporting evidence, Derived calculations
  • Version 1.5: 2019-11-27
    Changes: Author supporting evidence
  • Version 1.6: 2023-09-27
    Changes: Data collection, Database references, Refinement description
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection
