5HIZ | pdb_00005hiz

The structure of PEDV NSP9


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.334 (Depositor), 0.356 (DCC)
  • R-Value Work:
    0.272 (Depositor), 0.275 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 5HIZ

This is version 1.2 of the entry. See complete history

Literature

Dimerization of Coronavirus nsp9 with Diverse Modes Enhances Its Nucleic Acid Binding Affinity.

Zeng, Z.Deng, F.Shi, K.Ye, G.Wang, G.Fang, L.Xiao, S.Fu, Z.Peng, G.

(2018) J Virol 92

  • DOI: https://doi.org/10.1128/JVI.00692-18
  • Primary Citation Related Structures:
    5HIY, 5HIZ, 5YM6, 5YM8

  • PubMed Abstract:

    Coronaviruses pose serious health threats to humans and other animals. Understanding the mechanisms of their replication has important implications for global health and economic stability. Nonstructural protein 9 (nsp9) is an essential RNA binding protein for coronavirus replication. However, the mechanisms of the dimerization and nucleic acid binding of nsp9 remain elusive. Here, we report four crystal structures, including wild-type porcine delta coronavirus (PDCoV) nsp9, PDCoV nsp9-ΔN7 (N-terminal 7 amino acids deleted), wild-type porcine epidemic diarrhea virus (PEDV) nsp9, and PEDV nsp9-C59A mutant. These structures reveal the diverse dimerization forms of coronavirus nsp9. We first found that the N-finger of nsp9 from PDCoV plays a critical role in dimerization. Meanwhile, PEDV nsp9 is distinguished by the presence of a disulfide bond in the dimer interface. Interestingly, size exclusion chromatography and analytical ultracentrifugation analyses indicate that the PDCoV nsp9-ΔN7 and PEDV nsp9-C59A mutants are monomeric in solution. In addition, electrophoretic mobility shift assays and microscale thermophoresis analysis indicate that the monomeric forms of PDCoV nsp9 and PEDV nsp9 still have nucleic acid binding affinity, although it is lower than that of the wild type. Our results show that the diverse dimerization forms of coronavirus nsp9 proteins enhance their nucleic acid binding affinity. IMPORTANCE Coronaviruses cause widespread respiratory, gastrointestinal, and central nervous system diseases in humans and other animals, threatening human health and causing economic loss. Coronavirus nsp9, a member of the replication complex, is an important RNA binding subunit in the RNA-synthesizing machinery of all coronaviruses. However, the mechanisms of the dimerization and nucleic acid binding of nsp9 remain elusive. In this study we determined the nsp9 crystal structures of PDCoV and PEDV. We first found that the N-finger of nsp9 from PDCoV plays a critical role in dimerization. Meanwhile, PEDV nsp9 is distinguished by the presence of a disulfide bond in the dimer interface. This study provides a structural and functional basis for understanding the mechanism of dimerization and shows that the diverse dimerization modes of coronavirus nsp9 proteins enhance their nucleic acid binding affinity. Importantly, these findings may provide a new insight for antiviral drug development.


  • Organizational Affiliation
    • State Key Laboratory of Agricultural Microbiology, College of Veterinary Medicine, Huazhong Agricultural University, Wuhan, China.

Macromolecule Content

  • Total Structure Weight: 25.87 kDa
  • Atom Count: 1,498
  • Modeled Residue Count: 192
  • Deposited Residue Count: 228
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Non-structural protein 9
A, B
114Porcine epidemic diarrhea virus CV777Mutation(s): 0
Gene Names: rep1a-1b
UniProt
Find proteins for P0C6Y4 (Porcine epidemic diarrhea virus (strain CV777))
Explore P0C6Y4
Go to UniProtKB:  P0C6Y4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C6Y4
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.334 (Depositor), 0.356 (DCC)
  • R-Value Work:  0.272 (Depositor), 0.275 (DCC)
Space Group: P 64
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.87α = 90
b = 73.87β = 90
c = 91.553γ = 120
Software Package:
Software NamePurpose
PHENIXphasing
PHENIXrefinement
Blu-Icedata collection
HKL-3000data processing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-01-25
    Type: Initial release
  • Version 1.1: 2019-07-03
    Changes: Data collection, Database references
  • Version 1.2: 2024-10-30
    Changes: Data collection, Database references, Structure summary
