5GVX | pdb_00005gvx

Structural insight into dephosphorylation by Trehalose 6-phosphate Phosphatase (OtsB2) from Mycobacterium Tuberculosis

• PDB DOI: https://doi.org/10.2210/pdb5GVX/pdb

• Classification: HYDROLASE
• Organism(s): Mycobacterium tuberculosis H37Rv
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2016-09-07 Released: 2017-09-27
• Deposition Author(s): Shan, S., Min, H., Liu, T., Jiang, D., Rao, Z.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:
  0.258 (Depositor), 0.221 (DCC)
• R-Value Work:
  0.212 (Depositor)
• R-Value Observed:
  0.217 (Depositor)

Literature

Structural insight into dephosphorylation by trehalose 6-phosphate phosphatase (OtsB2) from Mycobacterium tuberculosis.

Shan, S., Min, H., Liu, T., Jiang, D., Rao, Z.

(2016) FASEB J 30: 3989-3996

• PubMed: 27572957
• DOI: https://doi.org/10.1096/fj.201600463R
• Primary Citation Related Structures:
  5GVX


• PubMed Abstract:


  Trehalose serves as a key structural component in the cell wall of Mycobacterium tuberculosis. M. tuberculosis trehalose-6-phosphate phosphatase (MtbTPP), an essential enzyme in the trehalose biosynthesis OtsAB pathway, catalyzes the dephosphorylation of trehalose-6-phosphate (trehalose-6-P) to generate trehalose, and plays a critical role in M. tuberculosis survival-associated cell wall formation and permeability. Therefore, MtbTPP (OtsB2) is considered a promising potential target for discovery of antimicrobial drugs. However, the absence of structural information of MtbTPP restrains our understanding of its underlying catalytic mechanism. Here, we report the high-resolution crystal structures of apo active MtbTPP and its trehalose-6-P bound complex. The apo structure presents a canonical haloacid dehalogenase superfamily structural fold plus an extra N-terminal domain. The catalytic center is located in a positively charged cleft between the hydrolase domain and the cap domain, demonstrating a highly conserved substrate binding pocket. The role of residues interacting with the substrate in catalysis were probed by site-directed mutagenesis. Asp147, Asp149, Asp330, and Asp331 were found to be pivotal for the enzymatic activity of MtbTPP. The MtbTPP structures reported here provide insight into a key step in the biosynthesis of trehalose, which would facilitate future development of anti-TB therapeutics.-Shan, S., Min, H., Liu, T., Jiang, D., Rao, Z. Structural insight into dephosphorylation by trehalose 6-phosphate phosphatase (OtsB2) from Mycobacterium tuberculosis.

---

Organizational Affiliation:
• National Laboratory of Biomacromolecules, Institute of Biophysics, Chinese Academy of Sciences, Beijing, China; [e-mail].
State Key Laboratory of Plant Genomics, Chinese Academy of Sciences, Beijing, China.
National Center for Plant Gene Research-Beijing, Institute of Genetics and Developmental Biology, Chinese Academy of Sciences, Beijing, China; and.
College of Life Sciences, Nankai University, Tianjin, China.
National Laboratory of Biomacromolecules, Institute of Biophysics, Chinese Academy of Sciences, Beijing, China.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 45.97 kDa
• Atom Count: 2,956
• Modeled Residue Count: 386
• Deposited Residue Count: 430
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Trehalose-phosphate phosphatase	A	430	Mycobacterium tuberculosis H37Rv	Mutation(s): 2  Gene Names: otsB, otsB2, Rv3372 EC: 3.1.3.12
UniProt
Find proteins for P9WFZ5 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WFZ5  Go to UniProtKB:  P9WFZ5

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MG	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:  0.258 (Depositor), 0.221 (DCC)
• R-Value Work:  0.212 (Depositor)
• R-Value Observed: 0.217 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.669	α = 90
b = 89.069	β = 90
c = 105.48	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
SHELXD	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2017-09-27
Deposition Author(s): Shan, S., Min, H., Liu, T., Jiang, D., Rao, Z.

Revision History

• Version 1.0: 2017-09-27
  Type: Initial release

• Version 1.1: 2017-12-06
  Changes: Database references
• Version 1.2: 2024-03-20
  Changes: Advisory, Data collection, Database references
