5G24 | pdb_00005g24

Type IV-like pilin TTHA1219 from Thermus thermophilus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.240 (Depositor), 0.240 (DCC)
  • R-Value Work:
    0.190 (Depositor), 0.196 (DCC)
  • R-Value Observed:
    0.193 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5G24

This is version 1.4 of the entry. See complete history

Literature

Structures of Type Iv Pilins from Thermus Thermophilus Demonstrate Similarities with Type II Secretion System Pseudopilins

Karuppiah, V.Thistlethwaite, A.Derrick, J.P.

(2016) J Struct Biol 196: 375

  • DOI: https://doi.org/10.1016/j.jsb.2016.08.006
  • Primary Citation Related Structures:
    5G23, 5G24, 5G25, 5G2F

  • PubMed Abstract:

    Type IV pilins are proteins which form polymers that extend from the surface of the bacterial cell; they are involved in mediating a wide variety of functions, including adhesion, motility and natural competence. Here we describe the determination of the crystal structures of three type IVa pilins proteins from the thermophile Thermus thermophilus. They form part of a cluster of pilus-like proteins within the genome; our results show that one, Tt1222, is very closely related to the main structural type IV pilin, PilA4. The other two, Tt1218 and Tt1219, also adopt canonical pilin-like folds but, interestingly, are most closely related to the structures of the type II secretion system pseudopilins, EpsI/GspI and XcpW/GspJ. GspI and GspJ have been shown to form a complex with another pseudopilin, GspK, and this heterotrimeric complex is known to play a key role in initiating assembly of a pseudopilus which is thought to drive the secretion process. The structural similarity of Tt1218 and Tt1219 to GspI and GspJ suggests that they might work in a similar way, to deliver functions associated with type IV pili in T. thermophilus, such as natural competence.


  • Organizational Affiliation
    • Michael Smith Building, Faculty of Life Sciences, University of Manchester, Oxford Road, Manchester, UK.

Macromolecule Content

  • Total Structure Weight: 50.25 kDa
  • Atom Count: 3,016
  • Modeled Residue Count: 394
  • Deposited Residue Count: 472
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
TYPE-IV LIKE PILIN TTHA1219
A, B
236Thermus thermophilus HB8Mutation(s): 0
UniProt
Find proteins for Q5SIZ5 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SIZ5
Go to UniProtKB:  Q5SIZ5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SIZ5
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.240 (Depositor), 0.240 (DCC)
  • R-Value Work:  0.190 (Depositor), 0.196 (DCC)
  • R-Value Observed: 0.193 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 116.83α = 90
b = 32.17β = 115.51
c = 108.12γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-09-14
    Type: Initial release
  • Version 1.1: 2016-09-28
    Changes: Database references
  • Version 1.2: 2016-12-07
    Changes: Database references
  • Version 1.3: 2024-01-10
    Changes: Data collection, Database references, Other, Refinement description
  • Version 1.4: 2024-11-13
    Changes: Structure summary
