5F91 | pdb_00005f91

Fumarate hydratase of Mycobacterium tuberculosis in complex with formate and allosteric modulator (N-(5-(azepan-1-ylsulfonyl)-2-methoxyphenyl)-2-(4-oxo-3,4-dihydrophthalazin-1-yl)acetamide)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.194 (Depositor), 0.195 (DCC)
  • R-Value Work:
    0.151 (Depositor), 0.153 (DCC)
  • R-Value Observed:
    0.153 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5F91

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Selective small molecule inhibitor of the Mycobacterium tuberculosis fumarate hydratase reveals an allosteric regulatory site.

Kasbekar, M.Fischer, G.Mott, B.T.Yasgar, A.Hyvonen, M.Boshoff, H.I.Abell, C.Barry, C.E.Thomas, C.J.

(2016) Proc Natl Acad Sci U S A 113: 7503-7508

  • DOI: https://doi.org/10.1073/pnas.1600630113
  • Primary Citation Related Structures:
    5F91, 5F92

  • PubMed Abstract:

    Enzymes in essential metabolic pathways are attractive targets for the treatment of bacterial diseases, but in many cases, the presence of homologous human enzymes makes them impractical candidates for drug development. Fumarate hydratase, an essential enzyme in the tricarboxylic acid (TCA) cycle, has been identified as one such potential therapeutic target in tuberculosis. We report the discovery of the first small molecule inhibitor, to our knowledge, of the Mycobacterium tuberculosis fumarate hydratase. A crystal structure at 2.0-Å resolution of the compound in complex with the protein establishes the existence of a previously unidentified allosteric regulatory site. This allosteric site allows for selective inhibition with respect to the homologous human enzyme. We observe a unique binding mode in which two inhibitor molecules interact within the allosteric site, driving significant conformational changes that preclude simultaneous substrate and inhibitor binding. Our results demonstrate the selective inhibition of a highly conserved metabolic enzyme that contains identical active site residues in both the host and the pathogen.


  • Organizational Affiliation
    • National Center for Advancing Translational Sciences, National Institutes of Health, Bethesda, MD 20850; Department of Chemistry, University of Cambridge, Cambridge CB2 1EW, United Kingdom;

Macromolecule Content

  • Total Structure Weight: 211.64 kDa
  • Atom Count: 14,886
  • Modeled Residue Count: 1,787
  • Deposited Residue Count: 1,980
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Fumarate hydratase class II
A, B, C, D
495Mycobacterium tuberculosis CDC1551Mutation(s): 0
Gene Names: fumCfumMT1130
EC: 4.2.1.2
UniProt
Find proteins for P9WN93 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WN93
Go to UniProtKB:  P9WN93
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WN93
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
5WJ

Query on 5WJ



Download:Ideal Coordinates CCD File
E [auth A],
K [auth C]
~{N}-[5-(azepan-1-ylsulfonyl)-2-methoxy-phenyl]-2-(4-oxidanylidene-3~{H}-phthalazin-1-yl)ethanamide
C23 H26 N4 O5 S
VAOCQWVGHHYUHT-UHFFFAOYSA-N
FMT

Query on FMT



Download:Ideal Coordinates CCD File
G [auth B]FORMIC ACID
C H2 O2
BDAGIHXWWSANSR-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
F [auth A],
H [auth B],
I [auth B],
J [auth B],
L [auth D]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.194 (Depositor), 0.195 (DCC)
  • R-Value Work:  0.151 (Depositor), 0.153 (DCC)
  • R-Value Observed: 0.153 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 175.212α = 90
b = 96.497β = 102.68
c = 124.376γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
autoPROCdata scaling
XDSdata reduction
BUCCANEERmodel building
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-06-22
    Type: Initial release
  • Version 1.1: 2016-07-13
    Changes: Database references
  • Version 1.2: 2017-11-22
    Changes: Advisory, Data collection, Database references, Derived calculations, Refinement description
  • Version 1.3: 2023-09-27
    Changes: Advisory, Data collection, Database references, Refinement description
