5EN6 | pdb_00005en6

Crystal structure of the Smu1-RED complex (SeMet) of Caenorhabditis elegans

PDB DOI: https://doi.org/10.2210/pdb5EN6/pdb

Classification: SPLICING
Organism(s): Caenorhabditis elegans
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2015-11-09 Released: 2016-04-20
Deposition Author(s): Ulrich, A.K.C., Wahl, M.C.
Funding Organization(s): German Research Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free:
0.321 (Depositor), 0.328 (DCC)
R-Value Work:
0.283 (Depositor), 0.292 (DCC)
R-Value Observed:
0.285 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5EN6

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of the Smu1-RED complex (SeMet) of Caenorhabditis elegans

Ulrich, A.K.C., Schulz, J.F., Kamprad, A., Schuetze, T., Wahl, M.C.

To be published.

Macromolecule Content

Total Structure Weight: 55.63 kDa
Atom Count: 3,186
Modeled Residue Count: 393
Deposited Residue Count: 494
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
SMU-1	A, B	184	Caenorhabditis elegans	Mutation(s): 0 Gene Names: smu-1, CC4.3, CELE_CC4.3
UniProt
Find proteins for G5EEG7 (Caenorhabditis elegans) Explore G5EEG7 Go to UniProtKB: G5EEG7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	G5EEG7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Suppressor of Mec and Unc defects	C, D	63	Caenorhabditis elegans	Mutation(s): 0 Gene Names: smu-2, CELE_Y49F6B.4, Y49F6B.4
UniProt
Find proteins for Q9N4U5 (Caenorhabditis elegans) Explore Q9N4U5 Go to UniProtKB: Q9N4U5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9N4U5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free: 0.321 (Depositor), 0.328 (DCC)
R-Value Work: 0.283 (Depositor), 0.292 (DCC)
R-Value Observed: 0.285 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 166.669	α = 90
b = 183.443	β = 90
c = 41.078	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
SHARP	phasing
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2016-04-20

Deposition Author(s):

Funding Organization	Location	Grant Number
German Research Foundation	Germany	WA1126/7-1

Revision History (Full details and data files)

Version 1.0: 2016-04-20
Type: Initial release
Version 1.1: 2024-11-13
Changes: Author supporting evidence, Data collection, Database references, Refinement description, Structure summary
