5DTI | pdb_00005dti

Crystal structure of mouse acetylcholinesterase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.224 (Depositor), 0.227 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.202 (DCC)
  • R-Value Observed:
    0.197 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5DTI

This is version 1.3 of the entry. See complete history

Literature

Discovery of New Classes of Compounds that Reactivate Acetylcholinesterase Inhibited by Organophosphates.

Katz, F.S.Pecic, S.Tran, T.H.Trakht, I.Schneider, L.Zhu, Z.Ton-That, L.Luzac, M.Zlatanic, V.Damera, S.Macdonald, J.Landry, D.W.Tong, L.Stojanovic, M.N.

(2015) Chembiochem 16: 2205-2215

  • DOI: https://doi.org/10.1002/cbic.201500348
  • Primary Citation Related Structures:
    5DTI, 5DTJ, 5HCU

  • PubMed Abstract:

    Acetylcholinesterase (AChE) that has been covalently inhibited by organophosphate compounds (OPCs), such as nerve agents and pesticides, has traditionally been reactivated by using nucleophilic oximes. There is, however, a clearly recognized need for new classes of compounds with the ability to reactivate inhibited AChE with improved in vivo efficacy. Here we describe our discovery of new functional groups--Mannich phenols and general bases--that are capable of reactivating OPC--inhibited AChE more efficiently than standard oximes and we describe the cooperative mechanism by which these functionalities are delivered to the active site. These discoveries, supported by preliminary in vivo results and crystallographic data, significantly broaden the available approaches for reactivation of AChE.


  • Organizational Affiliation
    • Department of Medicine/Division of Experimental Therapeutics, Columbia University Medical Center, 630 W. 168th Street, New York, NY 10032 (USA).

Macromolecule Content

  • Total Structure Weight: 120.01 kDa
  • Atom Count: 8,867
  • Modeled Residue Count: 1,068
  • Deposited Residue Count: 1,090
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Acetylcholinesterase
A, B
545Mus musculusMutation(s): 0
Gene Names: Ache
EC: 3.1.1.7
UniProt & NIH Common Fund Data Resources
Find proteins for P21836 (Mus musculus)
Explore P21836
Go to UniProtKB:  P21836
IMPC:  MGI:87876
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21836
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.224 (Depositor), 0.227 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.202 (DCC)
  • R-Value Observed: 0.197 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 78.411α = 90
b = 113.135β = 90
c = 227.199γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data collection
HKL-2000data scaling
MOLREPphasing
PDB_EXTRACTdata extraction
HKL-2000data reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-10-21
    Type: Initial release
  • Version 1.1: 2015-11-04
    Changes: Source and taxonomy
  • Version 1.2: 2023-09-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.3: 2024-11-20
    Changes: Structure summary
