5DK1 | pdb_00005dk1

S. erythraea trypsin mixed catalytic intermediate

PDB DOI: https://doi.org/10.2210/pdb5DK1/pdb

Classification: HYDROLASE
Organism(s): Saccharopolyspora erythraea
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2015-09-02 Released: 2017-03-08
Deposition Author(s): Blankenship, E., Lodowski, D.T.
Funding Organization(s): National Institutes of Health/National Eye Institute (NIH/NEI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 0.94 Å
R-Value Free:
0.117 (Depositor), 0.119 (DCC)
R-Value Work:
0.107 (Depositor), 0.109 (DCC)
R-Value Observed:
0.107 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5DK1

This is version 1.5 of the entry. See complete history.

Literature

High resolution structures of S. erythraeus trypsin throughout the catalytic cycle

Blankenship, E., Lodowski, D.T.

To be published.

Macromolecule Content

Total Structure Weight: 23.66 kDa
Atom Count: 2,400
Modeled Residue Count: 230
Deposited Residue Count: 230
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Trypsin	A	230	Saccharopolyspora erythraea	Mutation(s): 1 EC: 3.4.21.4
UniProt
Find proteins for P24664 (Saccharopolyspora erythraea) Explore P24664 Go to UniProtKB: P24664
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P24664
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 0.94 Å
R-Value Free: 0.117 (Depositor), 0.119 (DCC)
R-Value Work: 0.107 (Depositor), 0.109 (DCC)
R-Value Observed: 0.107 (Depositor)

Space Group: I 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.037	α = 90
b = 53.297	β = 91.97
c = 124.927	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data scaling
Coot	model building
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-03-08

Deposition Author(s):

Blankenship, E.

Funding Organization	Location	Grant Number
National Institutes of Health/National Eye Institute (NIH/NEI)	United States	EY019718

Revision History (Full details and data files)

Version 1.0: 2017-03-08
Type: Initial release
Version 1.1: 2017-09-13
Changes: Author supporting evidence
Version 1.2: 2017-11-22
Changes: Refinement description
Version 1.3: 2019-12-11
Changes: Author supporting evidence, Derived calculations
Version 1.4: 2023-09-27
Changes: Data collection, Database references, Refinement description
Version 1.5: 2024-10-23
Changes: Structure summary
