5D8A | pdb_00005d8a

Crystal structure of recombinant foot-and-mouth-disease virus A22-H2093F empty capsid


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:
    0.212 (Depositor), 0.210 (DCC)
  • R-Value Work:
    0.206 (Depositor), 0.205 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5D8A

This is version 1.3 of the entry. See complete history

Literature

Structure-based energetics of protein interfaces guides foot-and-mouth disease virus vaccine design.

Kotecha, A.Seago, J.Scott, K.Burman, A.Loureiro, S.Ren, J.Porta, C.Ginn, H.M.Jackson, T.Perez-Martin, E.Siebert, C.A.Paul, G.Huiskonen, J.T.Jones, I.M.Esnouf, R.M.Fry, E.E.Maree, F.F.Charleston, B.Stuart, D.I.

(2015) Nat Struct Mol Biol 22: 788-794

  • DOI: https://doi.org/10.1038/nsmb.3096
  • Primary Citation Related Structures:
    5AC9, 5ACA, 5D8A, 5DDJ

  • PubMed Abstract:

    Virus capsids are primed for disassembly, yet capsid integrity is key to generating a protective immune response. Foot-and-mouth disease virus (FMDV) capsids comprise identical pentameric protein subunits held together by tenuous noncovalent interactions and are often unstable. Chemically inactivated or recombinant empty capsids, which could form the basis of future vaccines, are even less stable than live virus. Here we devised a computational method to assess the relative stability of protein-protein interfaces and used it to design improved candidate vaccines for two poorly stable, but globally important, serotypes of FMDV: O and SAT2. We used a restrained molecular dynamics strategy to rank mutations predicted to strengthen the pentamer interfaces and applied the results to produce stabilized capsids. Structural analyses and stability assays confirmed the predictions, and vaccinated animals generated improved neutralizing-antibody responses to stabilized particles compared to parental viruses and wild-type capsids.


  • Organizational Affiliation
    • Division of Structural Biology, University of Oxford, Oxford, UK.

Macromolecule Content

  • Total Structure Weight: 80.76 kDa
  • Atom Count: 5,383
  • Modeled Residue Count: 663
  • Deposited Residue Count: 735
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
VP1211Foot-and-mouth disease virus AMutation(s): 0
UniProt
Find proteins for Q6PN23 (Foot-and-mouth disease virus A)
Explore Q6PN23
Go to UniProtKB:  Q6PN23
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6PN23
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
VP2218Foot-and-mouth disease virus AMutation(s): 1
UniProt
Find proteins for Q6PN23 (Foot-and-mouth disease virus A)
Explore Q6PN23
Go to UniProtKB:  Q6PN23
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6PN23
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
VP3221Foot-and-mouth disease virus AMutation(s): 0
UniProt
Find proteins for Q6PN23 (Foot-and-mouth disease virus A)
Explore Q6PN23
Go to UniProtKB:  Q6PN23
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6PN23
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
VP485Foot-and-mouth disease virus AMutation(s): 0
UniProt
Find proteins for Q6PN23 (Foot-and-mouth disease virus A)
Explore Q6PN23
Go to UniProtKB:  Q6PN23
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6PN23
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:  0.212 (Depositor), 0.210 (DCC)
  • R-Value Work:  0.206 (Depositor), 0.205 (DCC)
Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 327.57α = 90
b = 341.29β = 90
c = 363.58γ = 90
Software Package:
Software NamePurpose
CNSrefinement
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
CNSphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom089755

Revision History  (Full details and data files)

  • Version 1.0: 2015-09-23
    Type: Initial release
  • Version 1.1: 2015-09-30
    Changes: Database references
  • Version 1.2: 2015-10-14
    Changes: Database references
  • Version 1.3: 2024-01-10
    Changes: Data collection, Database references, Derived calculations, Refinement description
