5CJJ | pdb_00005cjj

The crystal structure of phosphoribosylglycinamide formyltransferase from Campylobacter jejuni subsp. jejuni NCTC 11168

• PDB DOI: https://doi.org/10.2210/pdb5CJJ/pdb

• Classification: TRANSFERASE
• Organism(s): Campylobacter jejuni subsp. jejuni NCTC 11168 = ATCC 700819
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2015-07-14 Released: 2015-07-29
• Deposition Author(s): Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.42 Å
• R-Value Free:
  0.290 (Depositor), 0.290 (DCC)
• R-Value Work:
  0.249 (Depositor), 0.249 (DCC)
• R-Value Observed:
  0.252 (Depositor)

Literature

The crystal structure of phosphoribosylglycinamide formyltransferase from Campylobacter jejuni subsp. jejuni NCTC 11168

Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 43.72 kDa
• Atom Count: 2,965
• Modeled Residue Count: 377
• Deposited Residue Count: 382
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphoribosylglycinamide formyltransferase	A, B	191	Campylobacter jejuni subsp. jejuni NCTC 11168 = ATCC 700819	Mutation(s): 0  Gene Names: purN, Cj0187c EC: 2.1.2.2
UniProt
Find proteins for Q0PBV2 (Campylobacter jejuni subsp. jejuni serotype O:2 (strain ATCC 700819 / NCTC 11168)) Explore Q0PBV2  Go to UniProtKB:  Q0PBV2

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	D [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4	F [auth B], G [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
GOL	C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL	E [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.42 Å
• R-Value Free:  0.290 (Depositor), 0.290 (DCC)
• R-Value Work:  0.249 (Depositor), 0.249 (DCC)
• R-Value Observed: 0.252 (Depositor)

Diffraction Data: https://doi.org/10.18430/m35cjj

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.162	α = 90
b = 65.162	β = 90
c = 368.905	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2015-07-29
Deposition Author(s): Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201200026C

Revision History

• Version 1.0: 2015-07-29
  Type: Initial release

• Version 1.1: 2017-09-27
  Changes: Author supporting evidence, Derived calculations, Source and taxonomy
• Version 1.2: 2019-12-11
  Changes: Author supporting evidence
• Version 1.3: 2024-11-20
  Changes: Data collection, Database references, Structure summary
