5C94

Infectious bronchitis virus nsp9


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.44 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.187
  • R-Value Observed: 0.189

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural basis for dimerization and RNA binding of avian infectious bronchitis virus nsp9.

Hu, T.Chen, C.Li, H.Dou, Y.Zhou, M.Lu, D.Zong, Q.Li, Y.Yang, C.Zhong, Z.Singh, N.Hu, H.Zhang, R.Yang, H.Su, D.

(2017) Protein Sci 26: 1037-1048

  • DOI: https://doi.org/10.1002/pro.3150
  • Primary Citation of Related Structures:
    5C94

  • PubMed Abstract:

    The potential for infection by coronaviruses (CoVs) has become a serious concern with the recent emergence of Middle East respiratory syndrome and severe acute respiratory syndrome (SARS) in the human population. CoVs encode two large polyproteins, which are then processed into 15-16 nonstructural proteins (nsps) that make significant contributions to viral replication and transcription by assembling the RNA replicase complex. Among them, nsp9 plays an essential role in viral replication by forming a homodimer that binds single-stranded RNA. Thus, disrupting nsp9 dimerization is a potential anti-CoV therapy. However, different nsp9 dimer forms have been reported for alpha- and beta-CoVs, and no structural information is available for gamma-CoVs. Here we determined the crystal structure of nsp9 from the avian infectious bronchitis virus (IBV), a representative gamma-CoV that affects the economy of the poultry industry because it can infect domestic fowl. IBV nsp9 forms a homodimer via interactions across a hydrophobic interface, which consists of two parallel alpha helices near the carboxy terminus of the protein. The IBV nsp9 dimer resembles that of SARS-CoV nsp9, indicating that this type of dimerization is conserved among all CoVs. This makes disruption of the dimeric interface an excellent strategy for developing anti-CoV therapies. To facilitate this effort, we characterized the roles of six conserved residues on this interface using site-directed mutagenesis and a multitude of biochemical and biophysical methods. We found that three residues are critical for nsp9 dimerization and its abitlity to bind RNA.


  • Organizational Affiliation

    State Key Laboratory of Biotherapy, West China Hospital, Sichuan University, and Collaborative Innovation Center for Biotherapy, Chengdu, 610041, P.R. China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Non-structural protein 9116Avian infectious bronchitis virus (strain M41)Mutation(s): 0
Gene Names: rep1a-1b
EC: 3.4.22
UniProt
Find proteins for P0C6Y3 (Avian infectious bronchitis virus (strain M41))
Explore P0C6Y3
Go to UniProtKB:  P0C6Y3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C6Y3
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.44 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.187
  • R-Value Observed: 0.189
  • Space Group: I 4 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 123.426α = 90
b = 123.426β = 90
c = 123.426γ = 90
Software Package:
Software NamePurpose
HKL-2000data scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of ChinaChina31370735
Sichuan Key Technology Support ProgramChina14zc1822

Revision History  (Full details and data files)

  • Version 1.0: 2016-06-29
    Type: Initial release
  • Version 1.1: 2020-06-24
    Changes: Database references, Derived calculations
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references
