5BN1 | pdb_00005bn1

Structure of Axe2-W215I, an acetyl xylan esterase from Geobacillus stearothermophilus

PDB DOI: https://doi.org/10.2210/pdb5BN1/pdb

Classification: HYDROLASE
Organism(s): Geobacillus stearothermophilus
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2015-05-25 Released: 2016-06-29
Deposition Author(s): Lansky, S., Alalouf, O., Shoham, Y., Shoham, G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.166 (Depositor), 0.178 (DCC)
R-Value Work:
0.144 (Depositor), 0.159 (DCC)
R-Value Observed:
0.145 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5BN1

This is version 1.1 of the entry. See complete history.

Literature

A unique octameric structure of Axe2, an intracellular acetyl-xylooligosaccharide esterase from Geobacillus stearothermophilus

Lansky, S., Alalouf, O., Solomon, H.V., Alhassid, A., Govada, L., Chayen, N.E., Belrahli, H., Shoham, Y., Shoham, G.

To be published.

Macromolecule Content

Total Structure Weight: 50.11 kDa
Atom Count: 4,113
Modeled Residue Count: 436
Deposited Residue Count: 438
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Acetyl xylan esterase	A, B	219	Geobacillus stearothermophilus	Mutation(s): 1 Gene Names: axe2 EC: 3.1.1.72
UniProt
Find proteins for Q09LX1 (Geobacillus stearothermophilus) Explore Q09LX1 Go to UniProtKB: Q09LX1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q09LX1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TRS Query on TRS Download:Ideal Coordinates CCD File SDF format, chain J [auth B] MOL2 format, chain J [auth B] mmCIF format, chain J [auth B]	J [auth B]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₄ H₁₂ N O₃ LENZDBCJOHFCAS-UHFFFAOYSA-O		Interactions Focus chain J [auth B] Interactions & Density Focus chain J [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain K [auth B] SDF format, chain C [auth A] MOL2 format, chain K [auth B] MOL2 format, chain C [auth A] mmCIF format, chain K [auth B] mmCIF format, chain C [auth A]	C [auth A], K [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain K [auth B] Interactions & Density Focus chain C [auth A] Focus chain K [auth B]
IMD Query on IMD Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A], F [auth A], H [auth B], I [auth B]	IMIDAZOLE C₃ H₅ N₂ RAXXELZNTBOGNW-UHFFFAOYSA-O		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Focus chain I [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Focus chain I [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain G [auth B] SDF format, chain D [auth A] MOL2 format, chain G [auth B] MOL2 format, chain D [auth A] mmCIF format, chain G [auth B] mmCIF format, chain D [auth A]	D [auth A], G [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain G [auth B] Interactions & Density Focus chain D [auth A] Focus chain G [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.166 (Depositor), 0.178 (DCC)
R-Value Work: 0.144 (Depositor), 0.159 (DCC)
R-Value Observed: 0.145 (Depositor)

Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 108.88	α = 90
b = 108.88	β = 90
c = 216.12	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-06-29

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2016-06-29
Type: Initial release
Version 1.1: 2024-01-10
Changes: Data collection, Database references, Refinement description
