5ARJ | pdb_00005arj

crystal structure of porcine RNase 4 D80A mutant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.282 (Depositor), 0.278 (DCC)
  • R-Value Work:
    0.207 (Depositor), 0.210 (DCC)
  • R-Value Observed:
    0.210 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5ARJ

This is version 1.3 of the entry. See complete history

Literature

Structural Basis of Substrate Specificity in Porcine Rnase 4.

Liang, S.Acharya, K.R.

(2016) FEBS J 283: 912

  • DOI: https://doi.org/10.1111/febs.13646
  • Primary Citation Related Structures:
    5AR6, 5ARJ, 5ARK, 5ARL

  • PubMed Abstract:

    RNase 4, a member of the RNase A superfamily with substrate preference for uridine, has roles in host defence, angiogenesis and neurodegenerative diseases. It also exhibits the highest interspecies amino acid sequence similarity amongst RNase A family members. However, compared to other members of the RNase A family, including eosinophil-derived neurotoxin, eosinophil cationic protein and angiogenin, little is known about the molecular basis of substrate specificity in RNase 4. Here we report high to medium resolution structures of native porcine RNase 4 (PL3), a 'substrate-specificity' determining mutant D80A and their respective complexes with deoxyuridine 5'-monophosphate (dUMP) and deoxycytidine 5'-monophosphate (dCMP). These structures provide insight into the structural basis of the uridine versus cytosine substrate specificity in RNase 4: in the D80A mutant (D80A•dCMP), the side chain of Arg101 is positioned further away from the substrate-binding pocket due to the loss of the Asp80 side chain, reducing the repulsion force on the less favoured dCMP from Arg101 and allowing the ligand to occupy the binding pocket. This can also explain the observation that the ligand in the D80A•dCMP complex is stabilized only by a small number of hydrogen bonds. Compared to the previously reported structure of the human RNase 4•2'-deoxyuridine 3'-phosphate complex, the structure of PL3•dUMP complex shows additional hydrogen bonds between the ligand and the protein. In addition, the interaction between Arg101 and the dUMP ligand is absent. These observed differences are probably the result of the flexibility and different 'positioning' of the phosphate group among the mononucleotide ligands. The atomic coordinates and structure factors for PL3 (5AR6), D80A (5ARJ), PL3∙dUMP (5ARK) and D80A∙dCMP (5ARL) complexes have been deposited with the Protein Data Bank, Research Collaboratory for Structural Bioinformatics, Rutgers University, New Brunswick, NJ, USA (http://www.rcsb.org/).


  • Organizational Affiliation
    • Department of Biology and Biochemistry, University of Bath, UK.

Macromolecule Content

  • Total Structure Weight: 62.66 kDa
  • Atom Count: 3,853
  • Modeled Residue Count: 481
  • Deposited Residue Count: 536
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
RIBONUCLEASE 4
A, B, C, D
134Sus scrofaMutation(s): 1
EC: 3.1.27
UniProt
Find proteins for P15468 (Sus scrofa)
Explore P15468
Go to UniProtKB:  P15468
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP15468
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.282 (Depositor), 0.278 (DCC)
  • R-Value Work:  0.207 (Depositor), 0.210 (DCC)
  • R-Value Observed: 0.210 (Depositor)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 30.832α = 92.04
b = 61.821β = 100.99
c = 68.887γ = 101.24
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-01-20
    Type: Initial release
  • Version 1.1: 2016-03-16
    Changes: Database references
  • Version 1.2: 2024-01-10
    Changes: Data collection, Database references, Other, Refinement description
  • Version 1.3: 2024-10-23
    Changes: Structure summary
