5AG1 | pdb_00005ag1

DyP-type peroxidase of Auricularia auricula-judae (AauDyPI) with meso- nitrated heme

PDB DOI: https://doi.org/10.2210/pdb5AG1/pdb

Classification: OXIDOREDUCTASE
Organism(s): Auricularia auricula-judae
Mutation(s): No

Deposited: 2015-01-27 Released: 2016-03-02
Deposition Author(s): Strittmatter, E., Piontek, K., Plattner, D.A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.215 (Depositor), 0.216 (DCC)
R-Value Work:
0.175 (Depositor), 0.175 (DCC)
R-Value Observed:
0.177 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.3 of the entry. See complete history.

Literature

Crystallographic Trapping of a Covalently Modified Heme in a Dye-Decolorizing Peroxidase

Strittmatter, E., Piontek, K., Plattner, D.A.

To be published.

Macromolecule Content

Total Structure Weight: 97.39 kDa
Atom Count: 7,815
Modeled Residue Count: 891
Deposited Residue Count: 892
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DYE-DECOLORIZING PEROXIDASE	A, B	446	Auricularia auricula-judae	Mutation(s): 0 EC: 1.11.1.19 (PDB Primary Data), 1.11.1.7 (UniProt)
UniProt
Find proteins for I2DBY1 (Auricularia auricula-judae) Explore I2DBY1 Go to UniProtKB: I2DBY1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	I2DBY1
Glycosylation
Glycosylation Sites: 3	Glycosylation Focus chain A Focus chain B
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C	2		N-Glycosylation	Interactions Focus chain C Interactions & Density Focus chain C
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
N7H Query on N7H Download:Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain U [auth B] MOL2 format, chain K [auth A] MOL2 format, chain U [auth B] mmCIF format, chain K [auth A] mmCIF format, chain U [auth B]	K [auth A], U [auth B]	DELTA-MESO NITROHEME C₃₄ H₂₉ Fe N₅ O₆ KYBKYUQKNYQUQX-GYHFSKQYSA-J		Interactions Focus chain K [auth A] Focus chain U [auth B] Interactions & Density Focus chain K [auth A] Focus chain U [auth B]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain S [auth B] SDF format, chain T [auth B] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B]	I [auth A], J [auth A], S [auth B], T [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain S [auth B] Focus chain T [auth B]
CAC Query on CAC Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain N [auth B] MOL2 format, chain D [auth A] MOL2 format, chain N [auth B] mmCIF format, chain D [auth A] mmCIF format, chain N [auth B]	D [auth A], N [auth B]	CACODYLATE ION C₂ H₆ As O₂ OGGXGZAMXPVRFZ-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain N [auth B] Interactions & Density Focus chain D [auth A] Focus chain N [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain P [auth B] SDF format, chain O [auth B] SDF format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain P [auth B] MOL2 format, chain O [auth B] MOL2 format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain P [auth B] mmCIF format, chain O [auth B] mmCIF format, chain F [auth A]	E [auth A] F [auth A] G [auth A] H [auth A] O [auth B] E [auth A], F [auth A], G [auth A], H [auth A], O [auth B], P [auth B], Q [auth B], R [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B]
FMT Query on FMT Download:Ideal Coordinates CCD File SDF format, chain L [auth A] MOL2 format, chain L [auth A] mmCIF format, chain L [auth A]	L [auth A]	FORMIC ACID C H₂ O₂ BDAGIHXWWSANSR-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Interactions & Density Focus chain L [auth A]
NO2 Query on NO2 Download:Ideal Coordinates CCD File SDF format, chain M [auth A] SDF format, chain V [auth B] MOL2 format, chain M [auth A] MOL2 format, chain V [auth B] mmCIF format, chain M [auth A] mmCIF format, chain V [auth B]	M [auth A], V [auth B]	NITRITE ION N O₂ IOVCWXUNBOPUCH-UHFFFAOYSA-M		Interactions Focus chain M [auth A] Focus chain V [auth B] Interactions & Density Focus chain M [auth A] Focus chain V [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.215 (Depositor), 0.216 (DCC)
R-Value Work: 0.175 (Depositor), 0.175 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66	α = 90
b = 46.78	β = 100.53
c = 148.15	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-03-02

Deposition Author(s):

Strittmatter, E.

Piontek, K.

Plattner, D.A.

Revision History (Full details and data files)

Version 1.0: 2016-03-02
Type: Initial release
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Derived calculations, Other, Structure summary
Version 2.1: 2024-01-10
Changes: Data collection, Database references, Refinement description, Structure summary
Version 2.2: 2024-10-16
Changes: Structure summary
Version 2.3: 2026-04-15
Changes: Data collection
