5A7L | pdb_00005a7l

TP901-1 CI NTD (res 1-80)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.236 (Depositor), 0.237 (DCC)
  • R-Value Work:
    0.216 (Depositor), 0.220 (DCC)
  • R-Value Observed:
    0.218 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5A7L

This is version 1.1 of the entry. See complete history

Literature

Structural and Dynamics Studies of a Truncated Variant of Ci Repressor from Bacteriophage Tp901-1.

Rasmussen, K.K.Frandsen, K.E.H.Boeri Erba, E.Pedersen, M.Varming, A.K.Hammer, K.Kilstrup, M.Thulstrup, P.W.Blackledge, M.Jensen, M.R.Lo Leggio, L.

(2016) Sci Rep 6: 29574

  • DOI: https://doi.org/10.1038/srep29574
  • Primary Citation Related Structures:
    5A7L

  • PubMed Abstract:

    The CI repressor from the temperate bacteriophage TP901-1 consists of two folded domains, an N-terminal helix-turn-helix DNA-binding domain (NTD) and a C-terminal oligomerization domain (CTD), which we here suggest to be further divided into CTD1 and CTD2. Full-length CI is a hexameric protein, whereas a truncated version, CI∆58, forms dimers. We identify the dimerization region of CI∆58 as CTD1 and determine its secondary structure to be helical both within the context of CI∆58 and in isolation. To our knowledge this is the first time that a helical dimerization domain has been found in a phage repressor. We also precisely determine the length of the flexible linker connecting the NTD to the CTD. Using electrophoretic mobility shift assays and native mass spectrometry, we show that CI∆58 interacts with the OL operator site as one dimer bound to both half-sites, and with much higher affinity than the isolated NTD domain thus demonstrating cooperativity between the two DNA binding domains. Finally, using small angle X-ray scattering data and state-of-the-art ensemble selection techniques, we delineate the conformational space sampled by CI∆58 in solution, and we discuss the possible role that the dynamics play in CI-repressor function.


  • Organizational Affiliation
    • Department of Chemistry, University of Copenhagen, Universitetsparken 5, Copenhagen, Denmark.

Macromolecule Content

  • Total Structure Weight: 9.13 kDa
  • Atom Count: 677
  • Modeled Residue Count: 80
  • Deposited Residue Count: 80
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
CI80Lactococcus phage TP901-1Mutation(s): 1
UniProt
Find proteins for O48503 (Lactococcus phage TP901-1)
Explore O48503
Go to UniProtKB:  O48503
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO48503
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.236 (Depositor), 0.237 (DCC)
  • R-Value Work:  0.216 (Depositor), 0.220 (DCC)
  • R-Value Observed: 0.218 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.72α = 90
b = 36.01β = 90
c = 38.77γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-07-27
    Type: Initial release
  • Version 1.1: 2024-01-10
    Changes: Data collection, Database references, Other, Refinement description
