4IRT | pdb_00004irt

Crystal structure of a putative neuraminidase (BACOVA_03493) from Bacteroides ovatus ATCC 8483 at 1.74 A resolution

PDB DOI: https://doi.org/10.2210/pdb4IRT/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Bacteroides ovatus ATCC 8483
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-01-15 Released: 2013-03-13
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.74 Å
R-Value Free:
0.205 (Depositor), 0.211 (DCC)
R-Value Work:
0.169 (Depositor), 0.181 (DCC)
R-Value Observed:
0.170 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4IRT

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a hypothetical protein (BACOVA_03493) from Bacteroides ovatus ATCC 8483 at 1.74 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 48.87 kDa
Atom Count: 3,827
Modeled Residue Count: 398
Deposited Residue Count: 414
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A	414	Bacteroides ovatus ATCC 8483	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A]	I [auth A], J [auth A], K [auth A], L [auth A], M [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A]	B [auth A] C [auth A] D [auth A] E [auth A] F [auth A] B [auth A], C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.74 Å
R-Value Free: 0.205 (Depositor), 0.211 (DCC)
R-Value Work: 0.169 (Depositor), 0.181 (DCC)
R-Value Observed: 0.170 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 101.457	α = 90
b = 48.051	β = 90
c = 88.599	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SOLVE	phasing
SCALA	data scaling
REFMAC	refinement
MOSFLM	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-03-13

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2013-03-13
Type: Initial release
Version 1.1: 2014-12-24
Changes: Structure summary
Version 1.2: 2017-11-15
Changes: Refinement description
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
Version 1.4: 2024-11-27
Changes: Data collection, Structure summary
