4ZBJ | pdb_00004zbj

UBN1 peptide bound to H3.3/H4/Asf1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free:
    0.235 (Depositor), 0.236 (DCC)
  • R-Value Work:
    0.208 (Depositor), 0.212 (DCC)
  • R-Value Observed:
    0.209 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4ZBJ

This is version 1.5 of the entry. See complete history

Literature

Ubinuclein-1 confers histone H3.3-specific-binding by the HIRA histone chaperone complex.

Daniel Ricketts, M.Frederick, B.Hoff, H.Tang, Y.Schultz, D.C.Singh Rai, T.Grazia Vizioli, M.Adams, P.D.Marmorstein, R.

(2015) Nat Commun 6: 7711-7711

  • DOI: https://doi.org/10.1038/ncomms8711
  • Primary Citation Related Structures:
    4ZBJ

  • PubMed Abstract:

    Histone chaperones bind specific histones to mediate their storage, eviction or deposition from/or into chromatin. The HIRA histone chaperone complex, composed of HIRA, ubinuclein-1 (UBN1) and CABIN1, cooperates with the histone chaperone ASF1a to mediate H3.3-specific binding and chromatin deposition. Here we demonstrate that the conserved UBN1 Hpc2-related domain (HRD) is a novel H3.3-specific-binding domain. Biochemical and biophysical studies show the UBN1-HRD preferentially binds H3.3/H4 over H3.1/H4. X-ray crystallographic and mutational studies reveal that conserved residues within the UBN1-HRD and H3.3 G90 as key determinants of UBN1-H3.3-binding specificity. Comparison of the structure with the unrelated H3.3-specific chaperone DAXX reveals nearly identical points of contact between the chaperone and histone in the proximity of H3.3 G90, although the mechanism for H3.3 G90 recognition appears to be distinct. This study points to UBN1 as the determinant of H3.3-specific binding and deposition by the HIRA complex.


  • Organizational Affiliation
    • 1] Department of Biochemistry and Biophysics, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania 19104, USA [2] Graduate Group in Biochemistry and Molecular Biophysics, Perelman School of Medicine, University of Pennsylvania, Philadelphia, Pennsylvania 19104, USA.

Macromolecule Content

  • Total Structure Weight: 41.56 kDa
  • Atom Count: 2,866
  • Modeled Residue Count: 338
  • Deposited Residue Count: 364
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Histone chaperone ASF1175Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: ASF1CIA1YJL115WJ0755
UniProt
Find proteins for P32447 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32447
Go to UniProtKB:  P32447
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32447
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Histone H377Xenopus laevisMutation(s): 1
UniProt
Find proteins for Q6PI79 (Xenopus laevis)
Explore Q6PI79
Go to UniProtKB:  Q6PI79
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6PI79
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Histone H484Xenopus laevisMutation(s): 0
UniProt
Find proteins for P62799 (Xenopus laevis)
Explore P62799
Go to UniProtKB:  P62799
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62799
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Ubinuclein-128Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NPG3 (Homo sapiens)
Explore Q9NPG3
Go to UniProtKB:  Q9NPG3
PHAROS:  Q9NPG3
GTEx:  ENSG00000118900
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NPG3
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MPD

Query on MPD



Download:Ideal Coordinates CCD File
H [auth A](4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
E [auth A]
F [auth A]
G [auth A]
I [auth B]
J [auth B]
E [auth A],
F [auth A],
G [auth A],
I [auth B],
J [auth B],
K [auth B],
L [auth B],
M [auth C]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free:  0.235 (Depositor), 0.236 (DCC)
  • R-Value Work:  0.208 (Depositor), 0.212 (DCC)
  • R-Value Observed: 0.209 (Depositor)
Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.024α = 90
b = 90.024β = 90
c = 120.734γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute on Aging (NIH/NIA)United StatesAG031862
American Heart AssociationUnited States12PRE12030157

Revision History  (Full details and data files)

  • Version 1.0: 2015-07-15
    Type: Initial release
  • Version 1.1: 2015-07-29
    Changes: Database references
  • Version 1.2: 2017-09-13
    Changes: Author supporting evidence, Derived calculations, Source and taxonomy
  • Version 1.3: 2019-12-18
    Changes: Author supporting evidence
  • Version 1.4: 2023-09-27
    Changes: Data collection, Database references, Refinement description
  • Version 1.5: 2024-10-30
    Changes: Structure summary
