4WRP | pdb_00004wrp

The C-terminal domain of gene product lpg0944 from Legionella pneumophila subsp. pneumophila str. Philadelphia 1

PDB DOI: https://doi.org/10.2210/pdb4WRP/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Legionella pneumophila subsp. pneumophila str. Philadelphia 1
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2014-10-24 Released: 2015-03-18
Deposition Author(s): Cuff, M.E., Evdokimova, E., Egorova, O., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.205 (Depositor), 0.213 (DCC)
R-Value Work:
0.162 (Depositor), 0.175 (DCC)
R-Value Observed:
0.165 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4WRP

This is version 1.2 of the entry. See complete history.

Literature

The C-terminal domain of gene product lpg0944 from Legionella pneumophila subsp. pneumophila str. Philadelphia 1.

Cuff, M.E., Evdokimova, E., Egorova, O., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 28.83 kDa
Atom Count: 2,177
Modeled Residue Count: 236
Deposited Residue Count: 244
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A, B	122	Legionella pneumophila subsp. pneumophila str. Philadelphia 1	Mutation(s): 0 Gene Names: lpg0944
UniProt
Find proteins for Q5ZWY9 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZWY9 Go to UniProtKB: Q5ZWY9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5ZWY9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.205 (Depositor), 0.213 (DCC)
R-Value Work: 0.162 (Depositor), 0.175 (DCC)
R-Value Observed: 0.165 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 43.352	α = 90
b = 60.714	β = 104.61
c = 57.523	γ = 90

Software Package:

Software Name	Purpose
HKL-3000	data reduction
MLPHARE	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-03-18

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2015-03-18
Type: Initial release
Version 1.1: 2023-12-27
Changes: Data collection, Database references, Derived calculations, Other, Source and taxonomy
Version 1.2: 2024-11-20
Changes: Structure summary
