4WKW | pdb_00004wkw

Crystal Structure of a Conserved Hypothetical Protein from Mycobacterium leprae Determined by Iodide SAD Phasing

PDB DOI: https://doi.org/10.2210/pdb4WKW/pdb

Classification: STRUCTURAL GENOMICS
Organism(s): Mycobacterium leprae Br4923
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2014-10-03 Released: 2014-10-22
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.235 (Depositor), 0.239 (DCC)
R-Value Work:
0.189 (Depositor), 0.192 (DCC)
R-Value Observed:
0.191 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of a Conserved Hypothetical Protein from Mycobacterium leprae

Seattle Structural Genomics Center for Infectious Disease (SSGCID), Dranow, D.M., Lukacs, C.M., Lorimer, D., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 50.95 kDa
Atom Count: 3,036
Modeled Residue Count: 382
Deposited Residue Count: 456
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A, B	228	Mycobacterium leprae Br4923	Mutation(s): 0 Gene Names: MLBr01485
UniProt
Find proteins for A0A0H3MQY4 (Mycobacterium leprae (strain Br4923)) Explore A0A0H3MQY4 Go to UniProtKB: A0A0H3MQY4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0H3MQY4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain E [auth B] SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain E [auth B] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain E [auth B] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B], E [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Focus chain E [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B] Focus chain E [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.235 (Depositor), 0.239 (DCC)
R-Value Work: 0.189 (Depositor), 0.192 (DCC)
R-Value Observed: 0.191 (Depositor)

Diffraction Data:

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 84.57	α = 90
b = 84.19	β = 113.52
c = 71.71	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XSCALE	data scaling
ARP	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-10-22

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2014-10-22
Type: Initial release
Version 1.1: 2017-11-22
Changes: Derived calculations, Other, Refinement description, Source and taxonomy
Version 1.2: 2023-12-27
Changes: Data collection, Database references, Refinement description
