4UF6

UCH-L5 in complex with ubiquitin-propargyl bound to an activating fragment of INO80G


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.69 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.238
  • R-Value Observed: 0.240

Starting Model: other
View more details

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Mechanism of Uch-L5 Activation and Inhibition by Deubad Domains in Rpn13 and Ino80G.

Sahtoe, D.D.Van Dijk, W.J.El Oualid, F.Ekkebus, R.Ovaa, H.Sixma, T.K.

(2015) Mol Cell 57: 887

  • DOI: https://doi.org/10.1016/j.molcel.2014.12.039
  • Primary Citation of Related Structures:
    4UEL, 4UEM, 4UF5, 4UF6

  • PubMed Abstract:

    Deubiquitinating enzymes (DUBs) control vital processes in eukaryotes by hydrolyzing ubiquitin adducts. Their activities are tightly regulated, but the mechanisms remain elusive. In particular, the DUB UCH-L5 can be either activated or inhibited by conserved regulatory proteins RPN13 and INO80G, respectively. Here we show how the DEUBAD domain in RPN13 activates UCH-L5 by positioning its C-terminal ULD domain and crossover loop to promote substrate binding and catalysis. The related DEUBAD domain in INO80G inhibits UCH-L5 by exploiting similar structural elements in UCH-L5 to promote a radically different conformation, and employs molecular mimicry to block ubiquitin docking. In this process, large conformational changes create small but highly specific interfaces that mediate activity modulation of UCH-L5 by altering the affinity for substrates. Our results establish how related domains can exploit enzyme conformational plasticity to allosterically regulate DUB activity. These allosteric sites may present novel insights for pharmaceutical intervention in DUB activity.


  • Organizational Affiliation

    Division of Biochemistry and Cancer Genomics Center, The Netherlands Cancer Institute, Plesmanlaan 121, 1066CX Amsterdam, the Netherlands.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
UBIQUITIN CARBOXYL-TERMINAL HYDROLASE ISOZYME L5
A, D, G, J
331Homo sapiensMutation(s): 0
EC: 3.4.19.12
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y5K5 (Homo sapiens)
Explore Q9Y5K5
Go to UniProtKB:  Q9Y5K5
PHAROS:  Q9Y5K5
GTEx:  ENSG00000116750
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y5K5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
POLYUBIQUITIN-B
B, E, H, K
76Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P0CG47 (Homo sapiens)
Explore P0CG47
Go to UniProtKB:  P0CG47
PHAROS:  P0CG47
GTEx:  ENSG00000170315
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0CG47
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
NUCLEAR FACTOR RELATED TO KAPPA-B-BINDING PROTEIN
C, F, I, L
65Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q6P4R8 (Homo sapiens)
Explore Q6P4R8
Go to UniProtKB:  Q6P4R8
PHAROS:  Q6P4R8
GTEx:  ENSG00000170322
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6P4R8
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.69 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.238
  • R-Value Observed: 0.240
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 152.084α = 90
b = 137.788β = 102.54
c = 98.916γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-03-04
    Type: Initial release
  • Version 1.1: 2015-09-09
    Changes: Database references
  • Version 1.2: 2017-09-13
    Changes: Data collection
  • Version 1.3: 2019-04-03
    Changes: Data collection, Derived calculations, Experimental preparation
  • Version 1.4: 2024-05-01
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
  • Version 1.5: 2024-10-23
    Changes: Derived calculations, Structure summary
