4UF1 | pdb_00004uf1

Deerpox virus DPV022 in complex with Bak BH3


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.206 (Depositor), 0.213 (DCC)
  • R-Value Work:
    0.178 (Depositor), 0.186 (DCC)
  • R-Value Observed:
    0.180 (Depositor)

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4UF1

This is version 2.2 of the entry. See complete history

Literature

Structural Basis of Deerpox Virus-Mediated Inhibition of Apoptosis.

Burton, D.R.Caria, S.Marshall, B.Barry, M.Kvansakul, M.

(2015) Acta Crystallogr D Biol Crystallogr 71: 1593

  • DOI: https://doi.org/10.1107/S1399004715009402
  • Primary Citation Related Structures:
    4UF1, 4UF2, 4UF3

  • PubMed Abstract:

    Apoptosis is a key innate defence mechanism to eliminate virally infected cells. To counteract premature host-cell apoptosis, poxviruses have evolved numerous molecular strategies, including the use of Bcl-2 proteins, to ensure their own survival. Here, it is reported that the Deerpox virus inhibitor of apoptosis, DPV022, only engages a highly restricted set of death-inducing Bcl-2 proteins, including Bim, Bax and Bak, with modest affinities. Structural analysis reveals that DPV022 adopts a Bcl-2 fold with a dimeric domain-swapped topology and binds pro-death Bcl-2 proteins via two conserved ligand-binding grooves found on opposite sides of the dimer. Structures of DPV022 bound to Bim, Bak and Bax BH3 domains reveal that a partial obstruction of the binding groove is likely to be responsible for the modest affinities of DPV022 for BH3 domains. These findings reveal that domain-swapped dimeric Bcl-2 folds are not unusual and may be found more widely in viruses. Furthermore, the modest affinities of DPV022 for pro-death Bcl-2 proteins suggest that two distinct classes of anti-apoptotic viral Bcl-2 proteins exist: those that are monomeric and tightly bind a range of death-inducing Bcl-2 proteins, and others such as DPV022 that are dimeric and only bind a very limited number of death-inducing Bcl-2 proteins with modest affinities.


  • Organizational Affiliation
    • Department of Biochemistry, La Trobe University, Melbourne, VIC 3058, Australia.

Macromolecule Content

  • Total Structure Weight: 22.61 kDa
  • Atom Count: 1,319
  • Modeled Residue Count: 157
  • Deposited Residue Count: 194
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Antiapoptotic membrane protein168Deerpox virus W-1170-84Mutation(s): 0
Gene Names: DpV84gp022
UniProt
Find proteins for Q08FX8 (Deerpox virus (strain Mule deer/United States/W-848-83/1983))
Explore Q08FX8
Go to UniProtKB:  Q08FX8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08FX8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Bcl-2 homologous antagonist/killer26Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q16611 (Homo sapiens)
Explore Q16611
Go to UniProtKB:  Q16611
PHAROS:  Q16611
GTEx:  ENSG00000030110
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16611
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4

Query on SO4



Download:Ideal Coordinates CCD File
C [auth A]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.206 (Depositor), 0.213 (DCC)
  • R-Value Work:  0.178 (Depositor), 0.186 (DCC)
  • R-Value Observed: 0.180 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.26α = 90
b = 93.26β = 90
c = 45.62γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
iMOSFLMdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-08-05
    Type: Initial release
  • Version 1.1: 2015-08-12
    Changes: Database references
  • Version 1.2: 2015-08-19
    Changes: Database references
  • Version 2.0: 2019-10-23
    Changes: Atomic model, Data collection, Other
  • Version 2.1: 2021-06-30
    Changes: Database references, Derived calculations, Source and taxonomy, Structure summary
  • Version 2.2: 2024-05-01
    Changes: Data collection, Database references, Refinement description
