4TQ4 | pdb_00004tq4

Structure of a UbiA homolog from Archaeoglobus fulgidus bound to DMAPP and Mg2+


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.255 (Depositor), 0.256 (DCC)
  • R-Value Work:
    0.215 (Depositor), 0.221 (DCC)
  • R-Value Observed:
    0.217 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4TQ4

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Structure of a Membrane-Embedded Prenyltransferase Homologous to UBIAD1.

Huang, H.Levin, E.J.Liu, S.Bai, Y.Lockless, S.W.Zhou, M.

(2014) PLoS Biol 12: e1001911-e1001911

  • DOI: https://doi.org/10.1371/journal.pbio.1001911
  • Primary Citation Related Structures:
    4TQ3, 4TQ4, 4TQ5, 4TQ6

  • PubMed Abstract:

    Membrane-embedded prenyltransferases from the UbiA family catalyze the Mg2+-dependent transfer of a hydrophobic polyprenyl chain onto a variety of acceptor molecules and are involved in the synthesis of molecules that mediate electron transport, including Vitamin K and Coenzyme Q. In humans, missense mutations to the protein UbiA prenyltransferase domain-containing 1 (UBIAD1) are responsible for Schnyder crystalline corneal dystrophy, which is a genetic disease that causes blindness. Mechanistic understanding of this family of enzymes has been hampered by a lack of three-dimensional structures. We have solved structures of a UBIAD1 homolog from Archaeoglobus fulgidus, AfUbiA, in an unliganded form and bound to Mg2+ and two different isoprenyl diphosphates. Functional assays on MenA, a UbiA family member from E. coli, verified the importance of residues involved in Mg2+ and substrate binding. The structural and functional studies led us to propose a mechanism for the prenyl transfer reaction. Disease-causing mutations in UBIAD1 are clustered around the active site in AfUbiA, suggesting the mechanism of catalysis is conserved between the two homologs.


  • Organizational Affiliation
    • Verna and Marrs McLean Department of Biochemistry and Molecular Biology, Baylor College of Medicine, Houston, Texas, United States of America.

Macromolecule Content

  • Total Structure Weight: 134.75 kDa
  • Atom Count: 9,132
  • Modeled Residue Count: 1,155
  • Deposited Residue Count: 1,212
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
prenyltransferase
A, B, C, D
303Archaeoglobus fulgidus DSM 4304Mutation(s): 0
Gene Names: AF_1648
Membrane Entity: Yes
UniProt
Find proteins for O28625 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16))
Explore O28625
Go to UniProtKB:  O28625
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO28625
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
DMA

Query on DMA



Download:Ideal Coordinates CCD File
G [auth A],
J [auth B],
M [auth C],
P [auth D]
DIMETHYLALLYL DIPHOSPHATE
C5 H12 O7 P2
CBIDRCWHNCKSTO-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
E [auth A]
F [auth A]
H [auth B]
I [auth B]
K [auth C]
E [auth A],
F [auth A],
H [auth B],
I [auth B],
K [auth C],
L [auth C],
N [auth D],
O [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.255 (Depositor), 0.256 (DCC)
  • R-Value Work:  0.215 (Depositor), 0.221 (DCC)
  • R-Value Observed: 0.217 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 54.605α = 90
b = 218.922β = 90.13
c = 65.292γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
MOLREPphasing
PDB_EXTRACTdata extraction
PHENIXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK)United StatesR01DK088057
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM098878
American Heart AssociationUnited States12EIA8850017
Cancer Prevention and Research Institute of Texas (CPRIT)United StatesR12MZ

Revision History  (Full details and data files)

  • Version 1.0: 2014-07-16
    Type: Initial release
  • Version 1.1: 2014-08-06
    Changes: Database references
  • Version 1.2: 2017-09-06
    Changes: Author supporting evidence, Derived calculations, Other, Refinement description, Source and taxonomy
  • Version 1.3: 2019-12-25
    Changes: Author supporting evidence
  • Version 1.4: 2023-09-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
