 4TLW | pdb_00004tlw

CARDS TOXIN, FULL-LENGTH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.55 Å
  • R-Value Free:
    0.244 (Depositor), 0.239 (DCC)
  • R-Value Work:
    0.198 (Depositor), 0.197 (DCC)
  • R-Value Observed:
    0.200 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4TLW

This is version 1.5 of the entry. See complete history.

Literature

Structure of CARDS toxin, a unique ADP-ribosylating and vacuolating cytotoxin from Mycoplasma pneumoniae.

Becker, A., Kannan, T.R., Taylor, A.B., Pakhomova, O.N., Zhang, Y., Somarajan, S.R., Galaleldeen, A., Holloway, S.P., Baseman, J.B., Hart, P.J.

(2015) Proc Natl Acad Sci U S A 112: 5165-5170

  • DOI: https://doi.org/10.1073/pnas.1420308112
  • Primary Citation Related Structures:
    4TLV, 4TLW

  • PubMed Abstract:

    Mycoplasma pneumoniae (Mp) infections cause tracheobronchitis and "walking" pneumonia, and are linked to asthma and other reactive airway diseases. As part of the infectious process, the bacterium expresses a 591-aa virulence factor with both mono-ADP ribosyltransferase (mART) and vacuolating activities known as Community-Acquired Respiratory Distress Syndrome Toxin (CARDS TX). CARDS TX binds to human surfactant protein A and annexin A2 on airway epithelial cells and is internalized, leading to a range of pathogenetic events. Here we present the structure of CARDS TX, a triangular molecule in which N-terminal mART and C-terminal tandem β-trefoil domains associate to form an overall architecture distinct from other well-recognized ADP-ribosylating bacterial toxins. We demonstrate that CARDS TX binds phosphatidylcholine and sphingomyelin specifically over other membrane lipids, and that cell surface binding and internalization activities are housed within the C-terminal β-trefoil domain. The results enhance our understanding of Mp pathogenicity and suggest a novel avenue for the development of therapies to treat Mp-associated asthma and other acute and chronic airway diseases.


  • Organizational Affiliation:
    • Department of Biochemistry.

Macromolecule Content

  • Total Structure Weight: 70.63 kDa
  • Atom Count: 4,657
  • Modeled Residue Count: 567
  • Deposited Residue Count: 611
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ADP-ribosylating toxin CARDS611Mycoplasmoides pneumoniae M129Mutation(s): 0
Gene Names: MPN_372, MP464
EC: 2.4.2
Membrane Entity: Yes
UniProt
Find proteins for P75409 (Mycoplasmoides pneumoniae (strain ATCC 29342 / M129 / Subtype 1))
Explore P75409
Go to UniProtKB:  P75409
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP75409
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.55 Å
  • R-Value Free:  0.244 (Depositor), 0.239 (DCC)
  • R-Value Work:  0.198 (Depositor), 0.197 (DCC)
  • R-Value Observed: 0.200 (Depositor)
Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 178.431α = 90
b = 178.431β = 90
c = 89.521γ = 120
Software Package:
Software NamePurpose
PHASERphasing
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-04-08
    Type: Initial release
  • Version 1.1: 2015-04-22
    Changes: Database references
  • Version 1.2: 2015-05-13
    Changes: Database references
  • Version 1.3: 2017-09-27
    Changes: Author supporting evidence, Database references, Derived calculations, Other, Refinement description, Source and taxonomy
  • Version 1.4: 2023-12-27
    Changes: Data collection, Database references, Refinement description
  • Version 1.5: 2024-11-20
    Changes: Structure summary
