4RAA

Crystal structure of a Putative exported protein (BF0058) from Bacteroides fragilis NCTC 9343 at 2.60 A resolution

PDB DOI: https://doi.org/10.2210/pdb4RAA/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Bacteroides fragilis NCTC 9343
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2014-09-09 Released: 2014-10-15
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.257
R-Value Work: 0.214
R-Value Observed: 0.216

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a Putative exported protein (BF0058) from Bacteroides fragilis NCTC 9343 at 2.60 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 41.74 kDa
Atom Count: 2,891
Modelled Residue Count: 354
Deposited Residue Count: 362
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative exported protein	A	362	Bacteroides fragilis NCTC 9343	Mutation(s): 0 Gene Names: BF9343_0057
UniProt
Find proteins for Q5LJ40 (Bacteroides fragilis (strain ATCC 25285 / DSM 2151 / CCUG 4856 / JCM 11019 / LMG 10263 / NCTC 9343 / Onslow / VPI 2553 / EN-2)) Explore Q5LJ40 Go to UniProtKB: Q5LJ40
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q5LJ40
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.257
R-Value Work: 0.214
R-Value Observed: 0.216
Space Group: C 1 2 1
Diffraction Data: https://doi.org/10.18430/M34RAA

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 127.8	α = 90
b = 55.21	β = 122.27
c = 81.33	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2014-10-15

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2014-10-15
Type: Initial release
Version 1.1: 2017-11-22
Changes: Refinement description
Version 1.2: 2018-01-24
Changes: Database references
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
Version 1.4: 2024-11-06
Changes: Data collection, Structure summary
