4R6D | pdb_00004r6d

Modified mTFP* for enhanced metal binding: co-crystallization with CuCl2

PDB DOI: https://doi.org/10.2210/pdb4R6D/pdb

Classification: FLUORESCENT PROTEIN
Organism(s): Clavularia sp.
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2014-08-25 Released: 2014-11-12
Deposition Author(s): Fischer, J., Quitterer, F., Groll, M., Eppinger, J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free:
0.194 (Depositor), 0.211 (DCC)
R-Value Work:
0.151 (Depositor), 0.165 (DCC)
R-Value Observed:
0.153 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4R6D

This is version 1.2 of the entry. See complete history.

Literature

Modified mTFP* for enhanced metal binding: co-crystallization with CuCl2

Fischer, J., Quitterer, F., Groll, M., Eppinger, J.

To be published.

Macromolecule Content

Total Structure Weight: 24.95 kDa
Atom Count: 2,080
Modeled Residue Count: 214
Deposited Residue Count: 215
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GFP-like fluorescent chromoprotein cFP484	A	215	Clavularia sp.	Mutation(s): 32
UniProt
Find proteins for Q9U6Y3 (Clavularia sp.) Explore Q9U6Y3 Go to UniProtKB: Q9U6Y3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9U6Y3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
PIA Query on PIA	A	L-PEPTIDE LINKING	C₁₄ H₁₅ N₃ O₄		ALA, TYR, GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free: 0.194 (Depositor), 0.211 (DCC)
R-Value Work: 0.151 (Depositor), 0.165 (DCC)
R-Value Observed: 0.153 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 38.198	α = 90
b = 67.656	β = 90
c = 84.271	γ = 90

Software Package:

Software Name	Purpose
PROTEUM PLUS	data collection
PHASER	phasing
REFMAC	refinement
PROTEUM PLUS	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-11-12

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-11-12
Type: Initial release
Version 1.1: 2023-09-20
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.2: 2023-12-06
Changes: Data collection
