4Q97

IgNAR antibody domain C1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.265
  • R-Value Observed: 0.266

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

The structural analysis of shark IgNAR antibodies reveals evolutionary principles of immunoglobulins.

Feige, M.J.Grawert, M.A.Marcinowski, M.Hennig, J.Behnke, J.Auslander, D.Herold, E.M.Peschek, J.Castro, C.D.Flajnik, M.Hendershot, L.M.Sattler, M.Groll, M.Buchner, J.

(2014) Proc Natl Acad Sci U S A 111: 8155-8160

  • DOI: https://doi.org/10.1073/pnas.1321502111
  • Primary Citation of Related Structures:
    2MKL, 4Q97, 4Q9B, 4Q9C

  • PubMed Abstract:

    Sharks and other cartilaginous fish are the phylogenetically oldest living organisms that rely on antibodies as part of their adaptive immune system. They produce the immunoglobulin new antigen receptor (IgNAR), a homodimeric heavy chain-only antibody, as a major part of their humoral adaptive immune response. Here, we report the atomic resolution structure of the IgNAR constant domains and a structural model of this heavy chain-only antibody. We find that despite low sequence conservation, the basic Ig fold of modern antibodies is already present in the evolutionary ancient shark IgNAR domains, highlighting key structural determinants of the ubiquitous Ig fold. In contrast, structural differences between human and shark antibody domains explain the high stability of several IgNAR domains and allowed us to engineer human antibodies for increased stability and secretion efficiency. We identified two constant domains, C1 and C3, that act as dimerization modules within IgNAR. Together with the individual domain structures and small-angle X-ray scattering, this allowed us to develop a structural model of the complete IgNAR molecule. Its constant region exhibits an elongated shape with flexibility and a characteristic kink in the middle. Despite the lack of a canonical hinge region, the variable domains are spaced appropriately wide for binding to multiple antigens. Thus, the shark IgNAR domains already display the well-known Ig fold, but apart from that, this heavy chain-only antibody employs unique ways for dimerization and positioning of functional modules.


  • Organizational Affiliation

    Department of Tumor Cell Biology, St. Jude Children's Research Hospital, Memphis, TN 38105; matthias.feige@stjude.org.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Novel antigen receptor
A, B
111Ginglymostoma cirratumMutation(s): 0
UniProt
Find proteins for Q90544 (Ginglymostoma cirratum)
Explore Q90544
Go to UniProtKB:  Q90544
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ90544
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.265
  • R-Value Observed: 0.266
  • Space Group: P 31
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 41.25α = 90
b = 41.25β = 90
c = 98.34γ = 120
Software Package:
Software NamePurpose
XDSdata scaling
PHASERphasing
REFMACrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2014-07-02
    Type: Initial release
  • Version 1.1: 2023-09-20
    Changes: Data collection, Database references, Refinement description
